8

www.jabsco.com

Designed for North American Market

52580 Series

â–  Long-life mechanical seal.

This compact pump offers acompromise between pump overall size and duty capability.

â–  Neoprene impeller is fitted as standard. Fitting: 1" NPT. Size: 6 â–  1,070 igph (4,850 lph) at 10ft (3m) totalhead @ 1,500 rpm.
1 /
2 " long x 5" wide x 4" high.(180mm x 120mm x 100mm). â–  By use of optional thinner cams, variableflows are obtainable to suit individual applications. Weight: 5lb (2.1kg).
Pulley DrivenPumps â–  Self Priming up to 15ft (4.5m) vertical lift. 52580-9001 Pump. â–  The open design of this pump allows debristo pass through without affecting the flowand reliability. For service and spare parts listing see page 140. â–  Space sealed for life bearings.

6400 Series

This pump offers all the benefits offlexible impeller pumps in a mid-size package with substantial flow rate and horizontally oriented ports.

Size: 8
1 /
16 " long x 5
7 /
8 " wide x 4
7 /
8 " high. Weight: 10
1 /
2 lb (4.8 kg). 6400-0004 Pump with neoprene impeller,full cam and mechanical seal. â–  62 usgpm (235 lpm) at 10ft (3m) total head@ 1750 rpm. 6400-0051 Pump with neoprene impeller,half cam and mechanical seal. â–  Self-priming to 10ft (3m) vertical lift. 6400-1051 Pump with neoprene impeller,half cam, mechanical seal, and short shaft for caterpillarengines. â–  Mechanical face seal. â–  Neoprene or nitrile impeller. For service and spare parts listing see page 120. â–  Double-row ball bearing. Fitting: 1
1 /
4 " NPT.

7420 Series

This pump offers all the benefits offlexible impeller pumps in a mid-size package with substantial flow rate and vertically oriented ports.

Fitting: 1
1 /
4 " NPT. Size: 8
1 /
16 " long x 5
1 /
8 " widex 5
1 /
16 " high. Weight: 10
1 /
2 lb (4.8 kg). â–  62 usgpm (235 lpm) at 10ft (3m) total head@ 1750 rpm. 7420-0004 Pump with neoprene impeller,full cam and mechanical seal. â–  Self-priming to 10ft (3m) vertical lift. 7420-1001 Pump with neoprene impeller,full cam, mechanical seal, andshort shaft for caterpillar engines. â–  Mechanical face seal. â–  Neoprene impeller. For service and spare parts listing see page 122. â–  Double-row ball bearing.

18370-0000

This pump is the largest pedestalmount flexible impeller utility type pump and provides the greatest flow rate and horizontally oriented ports.

Fitting: 2" NPT.
Flexible Impeller Pumps - Size: 10
7 /
8 " long x 8" wide x 5
1 /
16 " high. Weight: 19 lb (8.6 kg). 18370-0000 Pump with neoprene impeller,full cam and mechanical seal. â–  83 usgpm (314 lpm) at 10ft (3m) total head@ 1750 rpm. â–  Self-priming to 10ft (3m) vertical lift. For service and spare parts listing see page 129. â–  Mechanical face seal. â–  Neoprene or nitrile impeller.

66

â–  Two single row ball bearings.
