CENTRIFUGAL PUMPS SUBMERSIBLE PUMPS

FLOW RATE

C£=.

■ ■ ■

35 _ (10.5)

(»)" 25

(7.5)" 20

(«)" 15 (4.5)"

(3)

(1.5)-

(0)

iL500P iL280P iL200P iL200

(0)

100

(378)

200

(756)

300

(1135)

400

(1513)

500

(1892)

FLOW GPH (LPH)

SPECIFICATIONS


Model	iL500Plus	iL280Plus	iL200Plus	iL200
Pump Type	Centrifugal submersible and inline pump
Current	12V - 6 amp	12V - 4.5 amp	I2V - 4.5 amp	I2V - 2.8 amp
	24V - 3 amp	24V - 2.5 amp	24V- 2.5 amp
Head	32ft (9.7m)	32ft (9.7m)	32ft (9.7m)	25ft (7.6m)
Flow Rate	500 GPH (1920 LPH)	280GPH (I080LPH)	200GPH (760LPH)	200GPH (760LPH)
Rating	Continuously Rated*	Continuously Rated*	Continuously Rated*	Intermittent Rated**
Outlets	3/4" (19mm) ID hose	1/2" (13mm) ID hose	I/2" (I3mm) ID hose	3/8" (I0mm) & I/2" (I3mm) ID hose
Pressure	14 psi (0.96 bar)	14 psi (0.96 bar)	II psi (0.76 bar)	I4 psi (0.96 bar)
Body	Acetal	Acetal	Acetal	Styrene
Length	6.5" (165mm)	6.5" (165mm)	5.6" (I42mm)	5.I" (I30mm)
Diameter	1.5" (38mm)	1.5" (38mm)	I.5" (38mm)	I.4" (36mm)
Cable Length	I3ft (4m)	I3ft (4m)	3ft (4m)	3ft (Im)
Liquid	Fresh & Seawater / Diesel	Fresh & Seawater / Diesel	Fresh & Seawater / Diesel	Fresh & Seawater
Operating Temp	Water systems to I76°F (80°C)	Water systems to I76°F (80°C)	Water systems to I76°F (80°C)	Water systems to I40°F (60°C)

*Should not be run dry for long periods of time. **Should not be run dry for more than 20 minutes and rested for equal time.
