AMAZON MANUAL BILGE PUMPS - Jabsco - #8

Text version of the page

AMAZON BULKHEAD For surface mounting on bulkhead or deck  Repositionable ports and body offer an amazing 96 assembly variations  Complete with stainless steel handle, mounting clips and provision for safety lanyard  Sustainable outputs up to 45 lpm (10 gpm) Connections for 25mm (1") id hose 29240-000 Bulkhead pump c/w detachable handle AMAZON UNIVERSAL For mounting on bulkhead, through bulkhead, on deck, or through deck (with optional through deck kit).  Flow direction can be changed 180º by interchanging inlet and outlet ports  Optional push-fit inlet and outlet elbows swivel through 360º to increase flexibility of installation still further  Unique safety feature allows operation from both inside and outside the cabin (with optional through deck kit)  Quick release clamp ring gives fast access for blockage clearance  Complete with stainless steel handle, mounting clips and provision for safety lanyard  Impressive features are matched by impressive flow rate of up to 100 lpm (22 gpm)  Excellent solids handling ability for use with holding tanks Connections for 38mm (11/2") id hose 29270-0000 Universal pump, c/w detachable handle and one push-fit elbow 29279-0000 Optional through deck kit 29266-1000 Additional push-fit elbow AMAZON THRUDECK For mounting through deck or through bulkhead  The ultimate compact through deck pump with no less than 16 port variations relative to the body  Loosening just one screw lets you clear blockages or re-position the body anywhere through 360º relative to the handle position  Complete with stainless steel handle, mounting clips and provision for safety lanyard  Sleekly styled through deck kit and cover, with 4 mounting positions relative to the pump  Readily achievable 50 lpm (11 gpm) output Connections for 25mm (1") id hose 29250-0000 Thrudeck pump, c/w detachable handle and through deck kit AMAZON ACCESSORIES 29290-0020 Bilge strainer for 19mm (3/4") id hose 29290-0000 Bilge strainer for 25mm (1") id hose 29290-0010 Bilge strainer for 38mm (11/2") id hose 29295-0011 In-line non-return valve for 19mm (3/4") id hose 29295-0000 In-line non-return valve for 25mm (1") id hose 29295-0010 In-line non-return valve for 38mm (11/2") id hose AMAZON WARRIOR For mounting on deck or through deck (with optional through deck kit and bracket)  Robust, alloy body particularly suited to workboat and safety applications  Double diaphragm design gives maximum efficiency and added safety, because each side of the pump operates independently  Solid 18" handle assists sustained high outputs of up to 135 lpm (30 gpm) Connections for 38mm (11/2") id hose 29280-0000 Warrior pump, c/w detachable handle 29279-0000 Optional through deck kit 29289-0000 Under deck bracket (required for use with through deck kit) On bulkhead Through deck On deck On bulkhead Thru deck 3600 rotation Through deck On deck In-line Non-Return Valve Warranty: All products of the company are sold and all services of the company are offered subject to the company’s warranty and terms and conditions of sale, copies of which will be furnished upon request © Copyright 2002 ITT Industries ?????-???? Rev 07/02 Discover Jabsco at www.jabsco.com Jabsco, 20 Icon, Foothill Ranch, CA 92610 USA Tel: +1 949 609 5106 Fax: +1 949 859 1254 USA Jabsco, Bingley Road, Hoddesdon, Hertfordshire EN11 0BU Tel: +44 (0) 1992 450 145 Fax: +44 (0) 1992 467 132 UK Fluid Products Canada, 55 Royal Road, Guelph, Ontario N1H 1T1 Tel: +1 519 821 1900 Fax: +1 519 821 2569 CANADA NHK Jabsco Co Ltd, 3-21-10, Shin-Yokohama, Kohoku-ku, Yokohama 222 Tel: +81 (0) 45 475 8906 Fax: +81 (0) 45 475 8908 JAPAN Jabsco GmbH, Oststraße 28, 22844 Norderstedt Tel: +49 (0) 40 53 53 73 0 Fax: +49 (0) 40 53 53 73 11 GERMANY Bilge Strainer
