TECHNICAL DATA


Model	SILVER	CLASSIC/BASIC	COMPACT	COMPACT MICRO
Motor	nductlon type	nductlon type	DC 24V	DC 24V
Motor speed: 500-1500 r.p.m		1500 r.p.m	3.100 r.p.m	1.600-3.100 r.p.m
deduction	1:6	1:6	1:8	1:8
Strokes/sec	5/6/7/8	8.5 (50 Hz)	10	6/7/8/9/10/r
		10(60 Hz)
Setting	-ceyboard/dlsplay	digital timer	digital timer	-ceyboard/dlsplay
Timer	5/30/60/90/120	15-90sec	15-90sec	15-990 sec.
	150/180/210/240 sec			(15 by 15)
	continuous mode	continuous mode	continuous mode continuous mode
Start / Stop	door activated	door activated	door activated	door activated
Security	double on door	double on door	double on door	double on door
Mains	230 V, 50 Hz	230 V 50 Hz	230 V 50 Hz	230 V 50 Hz
	110 V, 60 Hz	110 V 60 Hz	110 V 60 Hz	110 V 60 Hz
^Dower	270 W	270 W	50 W	55 W
Dimensions	24x30x40 cm	24x26x40 cm	15x15x30 cm	15x15x30 cm
(WxHxD)	94x11.8x15.7 in	9.4x10.2x15.7 in	5.9x5.9x11.8 in	5.9x5.9x11.8 in
Weight:	20 Kg/44 lb	17 Kg/37.5 lb	7 Kg/15.4lb	7 Kg/15.4lb
Specifications subject to change without notice
ORDERING INFORMATION
Model		Volume	Cat. No.
BASIC		400 ml	470
BASIC PANORAMIC		400 ml	475
COMPACT		80 ml	085
.CLASSIC		400 ml	400
SILVER		400 ml	. 420
CLASSIC PANORAMIC		400 ml	500
COMPACT MICRO		80 ml	080
SILVER PANORAMIC		400 ml	520

Specify mains regulred (Cat.No. may change) OPTIONAL ACCESSORIES

PORTABAG stainless steel holder for 6 bags (400 ml)

PORTABAG stainless steel holder for 6 bags (80 ml)

Bags with filter and without are supplied Indifferent presentations

All the instruments carry a 3-year warranty on the mechanical parts.

All systems come with 50 polyethylene bags, user's guide, and power cable. '

Cat no.

2300 2380

Contact us in internet.

To see how the instruments works in a multimedia-demonstration, to buy instruments, accessories or consumables on-line visit our web page:

www.iul-inst.com

The IUL instrument owners who are registered in our web will have access to extra services like example of microbiology applications with our instruments, software updates, direct technical service and more.
