| | | (gß> | | |
| | | Tool specifications | | |
| | | |
| | | Ingersoll Rand | | |
| | | | | | | | | | | | | | | | | | | Model number(1) | Voltage (V) | | Max. torque (Nm) | Working torque (Nm) | Max. free speed (rpm) | Blows per minute | Weight with NiCd battery (kg) | Weight with Li-Ion battery (kg) | Overall length (mm) | Sound pressure (dBA) | | | | | | | | W040 | 7.2 | 1/4" hex QC | 54 | 2 - 40 | 2200 | 2500 | 1.30 | 1.20 | 178 | 84 | | | | W040SQ | 7.2 | 3/8" square | 54 | 2 - 40 | 2200 | 2500 | 1.30 | 1.20 | 178 | 84 | | | | W150QC | 14.4 | 1/4" hex QC | 203 | 34 - 176 | 2200 | 3000 | 2.30 | 2.05 | 209 | 91 | | | | W150 | 14.4 | 3/8" square | 203 | 34 - 176 | 2200 | 3000 | 2.30 | 2.05 | 208 | 91 | | | | W175 | 14.4 | 1/2" square | 237 | 34 - 176 | 2200 | 3000 | 2.30 | 2.05 | 208 | 90 | | | | W360 | 19.2 | 1/2" square | 488 | 34 - 380 | 1650 | 2200 | 3.10 | 2.80 | 228 | 90 | | | | W360P | 19.2 | 1/2" sq. (pin retainer) | 488 | 34 - 380 | 1650 | 2200 | 3.10 | 2.80 | 228 | 90 | | | | Ratchet Wrenches | | | | | | | | | | | R140 | 7.2 | 1/4" square | 34 | 7 - 34 | 225 | — | 1.40 | 1.30 | 272 | 74 | | | | R145 | 7.2 | 3/8" square | 34 | 7 - 34 | 225 | — | 1.40 | 1.30 | 272 | 74 | | | | R380 | 14.4 | 3/8" square | 94 | 14 - 81 | 225 | — | 2.00 | 1.90 | 315 | 80 | | | | R385 | 14.4 | 1/2" square | 94 | 14 - 81 | 225 | — | 2.00 | 1.90 | 315 | 80 | | | | Drills | | | | | | | | | | | | D040 | 7.2 | 6.5 mm chuck | 4.5 | — | 1100 | — | 1.20 | 1.15 | 176 | 63 | | | | D550 | 14.4 | 13 mm chuck | 62 | — | 360/1300 | — | 2.30 | 2.05 | 244 | 71 | | | | D650 | 19.2 | 13 mm chuck | 73 | — | 360/1300 | — | 2.60 | 2.10 | 244 | 76 | | | | Task Light | | | | | | | | | | | | TL10IQV | 7.2 to 19.2 | — | — | — | — | — | 1.20 | 1.05 | 211 — | | | | | | | | | | | | | | | | | | |
| | | Commitment More than just providing tools, the IQV Series reflects our commitment to providing the best cordless technologies in a way that's flexible and convenient for our customers, then backing them with the best warranty in the business. | | |
| | | |
| | | |
| | | IQV™ Serie | | |
| | I | |
| | | |
| | | The first family of Cordless Tools specifically engineered for heavy-duty industrial maintenance and automotive applications | | |
| | | |
| | | |
| | | I 1-year hassle-free tool and charger replacement. I 2-year (or 1,000 recharges) battery limited warranty. I 3-year tool and charger limited warranty* (except for the ratchet wrenches which benefit from a 2 year warranty). * Subject to registering on www. irtools. com/cordless site. | | |
| | | IQv™ WARRANTY | | |
| | | |
| | | Year | | |
| | | |
| | | Hassle-Free Tool & Chargei Replacement | | |
| | | Battery Limited Warranty | | |
| | | |
| | | REGISTRATION REQUIRED (irtoofe.com) | | |
| | | |
| | | |
| | | I All items sold individually. You buy what you need. I Flexibility to upgrade and expand. I Save money with our Kits offers ! | | |
| | | |
| | | (1) Tool alone, without battery. Charger and Batteries | | |
| | | |
| | | |
| | | Commitment to cordless | | |
| | | |
| | | | | | | | | | Model Output number Voltage (V) | Weight (kg) | | | | Battery Charger | | | | BC10 7.2 to 19.2 - | | | | Li-Ion Batteries | | | | | BL072 7.2 | 0.4 | | | | BL144 14.4 | 0.6 | | | | BL192 19.2 | 0.7 | | | | NiCd Batteries | | | | BN072 7.2 | 0.5 | | | | BN144 14.4 | 0.8 | | | | BN192 19.2 | 1.1 | | | | | | | | | |
| | | |
| | | One universal charger. Comprehensive line of cordless tools for service and production applications. Distinctive products, designed for customer needs. | | |
| | | |
| | | IIIUU | | |
| | | |
| | | |
| | | Kits in carrying case Include the tool plus two batteries (2 Li-Ion batteries or 2 NiCd batteries) and the charger. | | |
| | | Ingersoll Rand Industrial Technologies provides products, services and solutions that enhance our customers' energy efficiency, productivity and operations. Our diverse and innovative products range from complete pneumatics systems, tools and pumps to material and fluid handling systems and environmentally friendly microturbines. We also enhance productivity through solutions created by Club Car®, the global leader in golf and utility vehicles for businesses and individuals. www.irtools.com/cordless Distributed by: | | |
| | | |
| | | | | | | | | | | Kits with Li-Ion batteries | Kits with NiCd batteries | | | | | W040-2L | W040-2N | 1/4" hex quick change impact wrench | | | | W040SQ-2L | W040SQ-2N | 3/8" square drive impact wrench | | | | W150QC-2L | W150QC-2N | 1/4" hex quick change impact wrench | | | | W150-2L | W150-2N | 3/8" square drive impact wrench | | | | W175-2L | W175-2N | 1/2" square drive impact wrench | | | | W360-2L | W360-2N | 1/2" square drive impact wrench | | | | W360P-2L | W360P-2N | 1/2" sq. (pin retainer) impact wrench | | | | R140-2L | R140-2N | | | | | R145-2L | R145-2N | 3/8" square drive ratchet wrench | | | | R380-2L | R380-2N | 3/8" square drive ratchet wrench | | | | R385-2L | R385-2N | 1/2" square drive ratchet wrench | | | | D040-2L | D040-2N | 6.5 mm chuck mini drill | | | | D550-2L | D550-2N | 13 mm chuck drill / driver | | | | D650-2L | D650-2N | 13 mm chuck drill / driver | | | | | | | | | | |
| | | |
| | | Power • Durability • Commitment | | |
| | | Nothing contained within this brochure is intended to extend any warranty or representation, expressed or implied, regarding the products described herein. Any such warranties or other items or conditions of sale of products shall be in accordance with Ingersoll Rand' s standard terms and conditions of sale for such products, which are available upon request. Product improvement is a continuing goal at Ingersoll Rand. Designs and specifications are subject to change without notice or obligation. | | |
| | | |
| | | |
| | | |
| | | 5 | | |
| | | © 2008 Ingersoll Rand Company — Printed in France — Form No. E32540 — CPN: 17016478 | | |
| | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
