Infeed Systems – Heavy Duty InductoForge® Pinch Roll and Tractor Chain drive infeed systems push the billets through the InductoForge® coil line at a very accurate rate controlled by a variable frequency AC motor. Both systems automatically adjust for the diameter of the billet (for quick change-over). A lost motion detector will automatically shut down power to the system if the billets stop moving for any reason. Hot Billet Extraction – The Fastextractor™ equipment is manufactured to provide many years of low maintenance operation. Heavy-duty, multi-strand chain works with the gravity pinch...

8.25 TPH 16500 (7500) 2910 345 (1305) 607.44 (15429) 135 (3429) 413.39 (10500) 60 (1500) 61.5 (1562) 95 (2413) 142 ( 3600) 11000 (5000) 11 TPH 22000 (10000) 4075 420 (1590) 686.18 (17429) 135 (3429) 492.13 (12500) 60 (1500) 61.5 (1562) 95 (2413) 142 ( 3600) 13000 (5900) ©2010 Inductoheat, Inc. All Rights Reserved. 250. 04/10 BULLETIN F-70 Rev.4 Model Max. Rate lbs/hr (kg/hr) Input kVA (@Max. kW) Cooling Water gpm (lpm) A B C D E F G *Additional modules can be added as needed **Specifications subject to change without notice. Weight lbs. (kg) PHYSICAL DIMENSIONS - inches (mm) 1 Module 2 Module...
