AS-AR-AF insulating cable glands

complete insulating cable glandcomplete insulating cable gland • AS..I IP68 degree of protection (EN 60529) • ARP/AFPIP67 degree of protection (EN 60529)• temperature range -25 °C / +100 °C • metric threading according to EN 60423 andEN 50262• Pg threading according to DIN 40430 andDIN 46320• anti-aging rubber gaskets • AS C/AS M grey RAL7001, AS C11I / AS M20I grey RAL7035, AS C11IN / AS M20IN black RAL9005• UL, VDE, CSAapproval

descriptionpart No.Pg or Mpart No.Pgthreadingthreading - for cable Ø 3.5 - 10 mm AS C11I greyPg 11- for cable Ø 3.5 - 10 mm AS C11IN blackPg 11- for cable Ø 5 - 12 mm AS C13I Pg 13.5- for cable Ø 7 - 14 mm AS C16I Pg 16- for cable Ø 9 - 18 mm AS C21I Pg 21- for cable Ø 14 - 25 mm AS C29I Pg 29- for cable Ø 18 - 32 mm AS C36I Pg 36- for cable Ø 24 - 38.5 mm AS C42I Pg 42 - rubber hole Ø 7.5-10-12.5 mm - for cable Ø 5 - 12.5 mm AS M20I greyM 20 - for cable Ø 5 - 12.5 mm AS M20IN blackM 20 - for cable Ø 9 - 18 mm AS M25I M 25- for cable Ø 14 - 25 mm AS M32I M 32- for cable Ø 18 - 32 mm* AS M40I M 40- for cable Ø 24 - 38.5 mm* AS M50I M 50 ARP11 11- rubber hole Ø 7.5-10-12.5 mm ARP13 13.5- rubber hole Ø 7.5-10-12.5-15 mm AFP16 16- rubber hole Ø 10-13-16-19 mm AFP21 21- rubber hole Ø 18-21-24-27 mm AFP29 29- rubber hole Ø 24-27-30-33 mm AFP36 36- rubber hole Ø 30-33-36-39 mm ARP42 42- rubber hole Ø 36-39-42-45 mm ARP48 48 *for use with- lock nuts in thermoplastic material (page 11) - multipole connector enclosures CF/MF 32/48/50 - IP68 high protection multipole connector enclosures dimensions in mmdimensions in mm AS C..I - AS M..IARP/ AFP
Pg/MCHA ACBDPg
AS C..IACH Part No.ABCDPg 11 822 ARP11 192092411 13 924 ARP13.5 2219.592613.5 16 1027 AFP16 2421102916 21 1133 AFP21 3026103921 29 1142 AFP29 4129.5105029 36 1353 AFP36 5033.5105836 42 1360 ARP42 542812.56042 ARP48 6441.513.57748 AS M..IACH 20 1024 25 1033 32 1042 40 1053 50 1260 Dimensions indicated are not binding and may bechanged without prior notice.
