X Series E-Stops

XA Series

Operating Instructions

Removing the Contact Block

Check that the contact block is securely installed on the operator. When the emergency stop switch is properly assembled, the bayonet ring is in place as shown below. marking on the edge of the operator base with the TOP mark-ing on the contact block. Press the contact block onto the operator and turn the contact block clockwise until the bayonet ring clicks. First unlock the operator button. While pushing up the white bayonet ring, using a small screwdriver (width: 2.5 to 3 mm) if necessary, turn the contact block counterclockwise and pull out. Do not exert excessive force when using a screwdriver, otherwise the bayonet ring may be damaged. Notes for Installing the Contact Block
OverviewX Series E-StopsDoor Interlock SwitchesEnabling SwitchesBarriersAS-Interface Safety at Work Turn Turn counterclockwise marking Push Bayonet Ring PressTOP marking Notes for Removing the Contact Block TOP marking (contact block) 1. When the contact block is removed, the monitor contact (NO contact) is closed.2. While removing the contact block, do not exert excessive force, otherwise the switch may be damaged.

Removing the LED Unit

Pull out the LED unit while squeezing the latches on the LED unit using the LED unit removal tool (MT-101).

Panel Mounting

Remove the locking ring from the operator and check that the rubber gasket is in place. Insert the operator from panel front into the panel hole. Face the side with the anti-rotation tab on the operator upward, and tighten the locking ring. Operator Unit Anti-rotation Tab Rubber Gasket TOP side Squeeze the LED unit on the latches and pull out. Latches Locking Ring Notes for Panel Mounting To mount XA emergency stop switches onto a panel, tighten the locking ring to a tightening torque of 0.88 N·m maximum using ring wrench MT-001. Do not use pliers. Do not exert excessive force, otherwise the locking ring may be damaged.

Installing the LED Unit

Align the top of the LED unit with the TOP marking on the contact block. Push the LED unit into the contact block.

Installing the Contact Block

First turn the bayonet ring to the unlocked position. Bayonet Ring TOP side UnlockedLocked Align the small
