Timers
GT3 Series Accessories
Panel Mounting Accessories
Switches & Pilot LightsDisplay LightsRelays & SocketsTimersTerminal BlocksCircuit BreakersPanel Mount Sockets and Hold-Down Springs
Panel Mount SocketApplicable HD SpringsStyleAppearanceUse with TimersPart No.AppearancePart No. GT3A- (8-pin)GT3D- (8-pin) GT3W- (8-pin) GT3F- (8-pin) GT3S SR2P-51 8-Pin Solder Terminal SFA-40211-Pin Solder Terminal GT3A- (11-pin)GT3D- (11-pin) GT3W- (11-pin) GT3F- (11-pin) SR3P-51For information on installing the hold-down springs, see page 838.
Flush Panel Mount Adapter and Sockets that use an Adapter
AccessoryDescriptionAppearanceUse with TimersPart No. Panel Mount AdapterAdaptor for fl ush panel mounting GT3 timers All GT3 timers RTB-G01 Sockets for use with Panel Mount Adapter 8-pin screw terminal (Shown: SR6P-M08G for Wiring Socket Adapter)All 8-pin timers SR6P-M08G11-pin screw terminalAll 11-pin timers SR6P-M11G8-pin solder terminal All 8-pin timers SR6P-S0811-pin solder terminal All 11-pin timers SR6P-S11No hold down springs are available for fl ush panel mounting.
