Timers

GT3F Series

Instructions: Setting GT3F Series Timers

Switches & Pilot LightsDisplay LightsRelays & SocketsTimersTerminal BlocksCircuit Breakers

POWER Indicator Setting Knob Dial Selector0-1, 0-3, 0-6, 0-18, 0-60 Time Range Selector 1S, 10S

Base Time Ranges Dial Selector Time Range Selector Step 1Desired OperationSelectionRemarks Time range can be selected from 1S and 10S using a fl at screwdriver and fi ve different dials of 0 to 1, 0 to 3, 0 to 6, 0 to 18, and 0 to 60 are displayed in the six windows by turning the Dial Selector, allowing for selecting the best suited scale. Note that the switch does not turn infi nitely.0.1s to 1s0 to 11s0.1s to 3s0 to 30.1s to 6s0 to 60.1s to 10s0 to 110s0.3s to 300 to 30.6s to 600 to 61.8s to 180s0 to 186s to 600s0 to 60 Step 2Remarks Select a time range that contains the desired period of time. is set at 2.5, with Dial Selector 0 to 3 and Time Range Selector The set time is selected by turning the Setting Knob.Setting Examples:1. When the Setting Knob 1S selected, then the set time is 2.5 seconds.2. When the Setting Knob is set at 5.0, with Dial Selector 0 to 60 and Time Range Selector 10S selected, then the set time is 500 seconds.
