General Purpose Terminal Blocks

Complete Terminal Blocks Catalog - 16475 Terminal Blocks

Key features of IDEC terminal blocks include:

•• • • • Molded from UL94-V0 material with excellent fl ame- and shock-resistanceMount on a standard 35mm DIN rail Marking strips and dust covers are available Control circuit, power circuits, and fuse blocks, are available Sectional or one-piece construction

Switches & Pilot LightsDisplay LightsRelays & SocketsTimersTerminal BlocksCircuit Breakers Switches & Pilot LightsRelays & SocketsTimers Insulation Voltage 600V Dielectric Strength 2,500V AC, 1 minute Insulation Resistance 100MW minimum Operating Temperature –25 to +55ºC
Specifi cations Operating Humidity 45 to 85% RH

Selection Guide

DescriptionAppearancePageCurrentModular DIN RailTerminal Blocks 86110A to 150A Modular DIN RailFuse Holders 86310A maximum One-Piece DIN RailTerminal Blocks 86715A to 40A One-Piece Power Blocks (DIN rail and surface mount) 865200A to 350A
Terminal Blocks One-Piece DIN RailFuse Holders 86810A maximum DIN RailBreak-Out Modules 8771A maximum
Circuit Breakers

860
