A6 Series — Miniature Switches and Pilot Devices: 16mm

Key features:

• 16mm (5/8") mounting hole

• LED illumination

• Compact design saves space

• Momentary, Maintained, Selectors, and E-Stops

• Gold-clad Silver contacts for reliable low level switching

• Snap action contacts

• IP40 (dustproof) or IP65 (oiltight) versions

■|Mm UL Recognized ^CSACertified f f

fl»K_#RleNo.LR21451 f fL

at ■< a co'

IP40: Dustproof

IP65 Watertight/Oiltight

SPDT, DPDT

250V AC/DC

5V AC/DC, 1mA Gold-clad silver .110" Solder/ Quick Connect -25° to +55°C (no freezing) 45 to 85% RH

50mQ maximum (initial value) 100MQ minimum (500V DC megger) 10 to 55Hz, amplitude 1.5mm p-p

Damage limits: 500m/sec² (approx. 50G) Operating extremes: 200m/sec² (approx. 20G)

100,000 operations minimum (at full rated load)

Maintained: 100,000 operations minimum Momentary: 1,000,000 operations minimum Selector/Keylock: 250,000 operations minimum

Switch Unit: 2,000V AC, 1 min. between live/dead part and terminals of different poles;

1,000V AC, 1 minute between terminals of the same pole;

1,500V AC, 1 minute between contact and lamp terminals. Illumination Unit: 2,000V AC, 1 min. between live part/ground

20W/5 seconds or 260°C/3 seconds

Degree of Protection

Contact Configuration Maximum Voltage Thermal Current Minimum Applicable Load Contact Material Terminal Style Operating Temperature Operating Humidity Contact Resistance Insulation Resistance Vibration Resistance Shock Resistance Electrical Life

Mechanical Life

ST CD

Dielectric Strength

Soldering Temperature


	24V		120V		240V
Resistive	—		1.0A		0.5A
Inductive	—		0.7A		0.5A
Resistive	1.0A		0.2A		—
Inductive	0.7A		0.1A		—
	5V DC ±5%	6V AC/DC (±10%)		12V AC/DC (±10%)		24V AC/DC (±10%)
	8mA	AC: A, R, W, Y: 8mA G, S: 7mA DC: A, R, W, Y: 6mA G, S: 5mA		AC: 9mA DC: 8mA		AC: 9mA DC: 8mA

Operating Voltage

AC (50/60Hz) DC

CCD

l l

Rated Voltage/Current

AC Inductive Load, PF = 0.6 - 0.7; DC Inductive Load, L/R = 7ms.

LED lamp contains a built-in current limiting resistor and a protection diode.

LED's don't "burn out." Luminance is reduced to 50% of initial intensity after being lit for 50,000 hours continuously.
