RH Series
Complete Relay & Socket Catalog - 16475 Relays & Sockets
RH Series Compact Power Relays
SPDT through 4PDT, 10A contacts Compact power type relays
The RH series are miniature power relays with a large capacity. The RH relays feature 10A contact capacity as large as the RR series but in a miniature package. The compact size saves space.
Switches & Pilot LightsDisplay LightsRelays & SocketsTimersTerminal BlocksCircuit BreakersPart Number Selection
Part Number ContactModelBlade TerminalPCB TerminalCoil Voltage Code (Standard Stock in bold) Basic RH1B-URH1V2-UAC6V, AC12V, SPDT AC24V , AC110V, AC120V , AC220V, AC240V DC6V, DC12V , DC24V , DC48V, DC110VWith IndicatorRH1B-UL—With Check ButtonRH1B-UC— With Indicator and Check ButtonRH1B-ULC— Top Bracket MountingRH1B-UT— With Diode (DC coil only)RH1B-UDRH1V2-UDDC6V, DC12V , DC24V , DC48V, DC110VWith Indicator and Diode (DC coil only)RH1B-ULD— DC12V , DC24V , DC48V, DC110VDPDT Basic RH2B-URH2V2-UAC6V, AC12V, AC24V , AC110-120V , AC220-240V DC6V, DC12V , DC24V , DC48V, DC100-110VWith IndicatorRH2B-ULRH2V2-ULWith Check ButtonRH2B-UC— With Indicator and Check ButtonRH2B-ULC— Top Bracket MountingRH2B-UT— With Diode (DC coil only)RH2B-UDRH2V2-UDDC6V, DC12V , DC24V , DC48V, DC100-110VWith Indicator and Diode (DC coil only)RH2B-ULD—3PDT Basic RH3B-URH3V2-UAC6V, AC12V, AC24V , AC110V, AC120V , AC220V, AC240V DC6V, DC12V , DC24V , DC48V, DC110VWith IndicatorRH3B-ULRH3V2-ULWith Check ButtonRH3B-UC— With Indicator and Check ButtonRH3B-ULC— Top Bracket MountingRH3B-UT— With Diode (DC coil only) RH3B-D* RH3V2-D*DC6V, DC12V, DC24V, DC48V, DC110VWith Indicator and Diode (DC coil only)RH3B-LD*—4PDT Basic RH4B-URH4V2-UAC6V, AC12V, AC24V , AC110V, AC120V , AC220V, AC240V DC6V, DC12V , DC24V , DC48V, DC110VWith IndicatorRH4B-ULRH4V2-ULWith Check ButtonRH4B-UC— With Indicator and Check ButtonRH4B-ULC— Top Bracket MountingRH4B-UT— With Diode (DC coil only)RH4B-UDRH4V2-UDDC6V, DC12V, DC24V, DC48V, DC110VWith Indicator and Diode (DC coil only) RH4B-LD*—1. *Carries no UL recognition mark.2. PCB terminal relays are designed to mount directly to a circuit board without any socket.
