107113118 Housing PlasticMetal Mounting DIN Rail or surface mountPanel or bracket mount Wattage Range 10W to 240W7.5W to 240W10W to 300W Input Voltage 85 to 264 V AC, 100-370 V DC (100-350V DC, 120W & 240W)85 to 264V AC, 105 to 370V DC85 to 264V AC, 105 to 370V DC 2.0A1.5A, 2.5A2A, 3A, 6A Output Current Ratings5VDC 12VDC 1.2A, 2.5A0.6A, 1.2A, 2.5A0.90A, 1.4A, 2.5A, 4.3A, 8.5A, 13A 24VDC 0.65A, 1.3A, 2.5A, 3.75A, 5A, 10A0.30A, 0.60A, 1.3A, 2.1A, 3.1A, 4.2A, 5A, 10A0.50A, 0.70A, 1.3A, 2.2A, 4.5A, 6.5A, 12.5A 5VDC
69%69% 70-75% 75%, 78%73% to 75%74% to 80% Typical Effi ciency 12VDC 24VDC 80% to 84%75% to 85%78% to 82% Voltage Adjustments +/-10% (V.ADJ control on front) Ripple Voltage 2% peak to peak max (including noise)160mV maximum Overvoltage Protection (input) 120% or more, auto reset120% typical Overcurrent Protection (output) 105% min shutdown105% minimum (Zener or auto reset) Operating Temperature -10Ëš to +60ËšC (14Ëš to 140ËšF) Termination
M3.5 phillip/slotted, spring loaded, captive (fi ngersafe)IEC Style screw terminals (fi ngersafe) UL1604 ListedFile#E234997 UL508 ListedFile #E177168Cert No.BL980213332392 UL508 Listed File #E177168 Approvals
(SEMI F47 120W & 240W only)
