Programmable Logic Controllers ONC Series
8-Point AC Input Module
PLCsOperator InterfacesAutomation SoftwarePower SuppliesSensorsCommunication & NetworkingAC Input ModuleFC3A-N08A11
Features: Specifi cations
Input Operating RangeInput Internal Circuit
8 points per card, 7 cards local, 8 cards expansion, 15 cards max. per CPU100-120V AC rated input voltage 85-132V AC input voltage range On/off detection set at 20ms Convenient termination connector, removable screw terminal blocks••• • •
InputAC Part Number FC3A-N08A11ConnectorRemovable screw terminal blocks Input Voltage Range85-132V AC Input Voltage100-120V AC Current Per Point8mA Internal Current - all inputs ON30mA Input Impedance12k (60Hz) On/Off Voltage79/20V AC On/Off Time20ms
COM 100 InputInternal Circuit TransitionOFF Area 132792001.611Input Current (mA) ON AreaArea
Input Voltage (V AC) 6.5 8.3
