LHZ Series Rack Panel connector incorporating Antenna link for GPS or ERTMS transmissions

•Railways approved float mount connector.•Modular type, with mixed power signal and coaxcontacts.•Featuring 1 coaxial contact #8 (GPS or ERTMS). •Single size: 14 units (5.5mm).•Cable length: from 0.25m to 5.0m, by multiple of0.25m.

About ERTMS

The European Rail Traffic Management System (ERTMS) was originated by the European Community (EC) to create a unique Automatic Train Control and railways management system to enable interoperability throu- ghout the European rail network. ERTMS is the combination of the new control-command system ETCS (European Train Control System) and the new GSM-R radio system for voice and data communication. The ERTMSproject has been set up to ensure safe operation of the trains in the network and to deal with the traffic and infrastructure management issues enabling the optimisation of the capacity of the lines and the utili- sation of the fleet. The ERTMSproject involves 6 major suppliers in 7 countries (UK, France, Spain, the Netherlands, Germany, Switzerland and Italy).

Connector Configurations

PanelRack CableCableTo AntennaMale #8 Coax ContactFemale #8 Coax Contact

06 12 LHS -48 02 00 14 06 12

TNCorNorBlunt Cut

HYPERTAC HYPERTAC

TNCorNorBlunt CutTo Electronic circuit

LHS 548 01 00 14

HYPERBOLOID Plug ConnectorReceptacle connector
