Dielectric hood (plug only) > Reinforced - Inox hood - (plug only) > Reversed polarity (consult us) > Single row without extractor jackscrew > Single row with extractor jackscrew > Single row with 1/2 turn jackscrew > Double row without strengthened central bar > Double row with strengthened central bar > Module V For mixed composition :fill in H Module Configurator˻ formulary and send it to HYPERTAC SA > Extension* * without contacts > 07 to 35 Single row (from 7 to 35 pitches) 38 to A5 Double row (from 19 to 55 pitches) >
Open the catalog to page 2Width is 2 units45 Hypertac > crimp contactsΘ 0.40mm contacts > Crimp 26 AWG Wire stripped back 3.10YPN004-010H (pin)YSK004-020AH (socket) Current Rating1 amps Contact Resistance< 8 milliohms Extraction Force8.5 - 45 gr. Contact Life Cycles>100,000Dielectric Withstanding > 30 Burried pinsOutside socket Voltage500 VRMS Insulation Resistance>10 > 3 Megohms > 1.65 Temperature Rating-55C +125аC InsulatorGlass filled nylon > 1.6523.1 0.4 Contact MaterialCopper alloyPlating referenceNi >1 m m+Au > 0,25 m mon mating surface only. > 4.654.41111 - the female modules must be already fitted into the standard...
Open the catalog to page 4Width is 4 units2 Hypertac high-voltage contactsΘ 1.20 mm contacts > Current Rating5 amps Contact Resistance< 3 milliohms > Hole 1.10ؘ 1.50 Extraction Force40 -120 gr. Contact Life Cycles>100,000Dielectric Withstanding Voltage6000 VRMS Insulation Resistance> 5 x 10 > 3 Megohms > 22.0030.00 11.0013.00 Temperature Rating-55C +125аC InsulatorGlass filled nylon > 18.5022.50 11.0013.00 Contact MaterialCopper alloyPlating referenceNi >1 m m+Au > 0,25 m mon mating surface only. > Hole 1.10ؘ 1.50 10.16 MaleHM FemaleHF > =12.70=30.00 Notes:- For empty block, order MH Width is 4 units2 Hypertac Power up...
Open the catalog to page 5Width is 2.5 units4 Hypertac contacts (on both signal & ground) > Ref.20(Crimp)Ref.40(Solder) Nominal impedance50 ohms Frequency RangeDC 3 GHz with RG316 DC 18 GHz with RG405. Temperature Rating-55ΰC to 125CMaterialsBrass Beryllium Copper PTFE Fluorocarbon Center Contacts Gold over nickel HousingsOver copper WireGold over nickel Voltage Standing Wave Ratio(DC to 3GHz) 1.20: 1 Max. (based on RG405 semi rigid cable)(3GHz to 18GHz) 1.50: 1 Max. RF Tranmission Loss 0.50 dB Max.@18 GHz Insulation Resistance5,000 megohms min. Dielectric Withstanding Voltage500 VRMS Contact Resistance inner Contact8...
Open the catalog to page 7Notes : (1)See panel mounting dimensions page (2)Standard length for p.c. boards (3)For thicker chassis, specify longer studs consult us-See ordering information, page > Notes : (1) See panel mounting dimensions pageSee ordering information page Dimensions are in mm >
Open the catalog to page 8Plug > Push, 1/4 turn locking hardwareSingle row, rack and panel with keying Built-in pin protection 36 possible keying combinations Standard sizes: 7, 11, 15, 19, 23, 27, 31 & 35 unit lengths Up to 350 contacts on 2.54 x 2.54 centers Mated length 23.50 SEQUENCE OF MODULES Receptacle > Notes: (1) See panel mounting dimensions pageSee ordering information page Plug > Float mounting [Max. radial play 0.60] Single row, rack and panel with keying Built-in pin protection 36 possible keying combinations Standard sizes: 7, 11, 15, 19, 23, 27, 31 & 35 unit lengths Up to 350 contacts on 2.54 x 2.54 centers...
Open the catalog to page 9HJ Up to 320 contacts on 2.54 x 2.54 centers Mated length 142 > Hooded with cable clamp 12.5 to 25mmJackscrew extractor Allow 3 units for jackscrew Single row, rack and panel with keying Built-in pin protection 36 possible keying combinations Standard sizes: 11, 15, 19, 23, 27, 31 & 35 unit lengths Cable clamp will hold 80 to 320 conductors of 22 to 28 AWG Mates with plug type SEQUENCE OF MODULES > Notes: (1) See panel mounting dimensions pageSee ordering information page Hooded with cable clamp ؘ12.5 to 25mm Jackscrew extractor Allow 3 units for jackscrew Single row, rack and panel with keying...
Open the catalog to page 11HC Up to 320 contacts 2.54 x 2.54 centers Mated length 92.50 > Hooded for programming applicationsJackscrew extractor Allow 3 units for jackscrew Single row, rack and panel with keying Built-in pin protection 36 possible keying combinations Standard sizes: 7, 11, 15, 19, 23, 27, 31 & 35 unit lengths Mates with receptacle type SEQUENCE OF MODULES > Notes: (1)See panel mounting dimensions page-See ordering information page -Mating face cover H_-- A n units > Ruggedized version usingHmodules in DIN 43652 metal panel housings & hoods. Frame for modules is made from Aluminium. 3 sizes of shell are...
Open the catalog to page 12Jackscrew extractor takes 5 modules space only for 35 to 55 unit lengths Double row, rack and panel with keying Built-in pin protection 36 possible keying combinations Standard sizes: 19, 23, 27, 31 & 35 to 55 unit lengths Up to1000 contacts on 2.54 x 2.54 centers Mated length 110 Notes: (1)See panel mounting dimensions page (2)Standard length for p.c. boards (3)For thicker chassis, specify longer studs consult us-See ordering information page -Mating face cover H_-- 284 n units Plug > Sequence of modules viewfrom receptacle mating side Dimensions are in mm 228 > APRIL 2005 size="-2">
Open the catalog to page 14Hooded with cable clamp 16 to 50mm Jackscrew extractor takes 5 modules space only for 35 to 55 unit lengths Double row, rack and panel with keying Built-in pin protection 36 possible keying combinations Standard sizes: 19, 23, 27, 31 & 35 to 55 unit lengths Mates with receptacle type HL Up to1000 contacts on 2.54 x 2.54 centers Possible double cable clamp, consult us Mated length 110 > Sequence of modules viewfrom plug mating side > Notes : (1) See panel mounting dimensions page-See ordering information page-Mating face cover H_-- 284 n units > Dimensions are in mm APRIL 2005
Open the catalog to page 15Jackscrew extractor takes 3 modules space 1/2 turn jack takes 5 modules space Single row, rack and panel with keying Built-in pin protection 36 possible keying combinations Standard sizes: 07, 11, 15, 19, 23, 27, 31 & 35 unit lengths Up to 320 contacts on 2.54 x 2.54 centers Mated length 92.5 > Effective shielding> 40 dB to 200 MHz Temperature Rating-55C to 125аCMaterials Guiding, coding and locking systemStainless steel Central polarisation system Stainless steel FrameAnodized aluminium, PBT, Polyamide, polycarbonateMating and unmating life cycles5,000 with jackscrew 15,000 with 1/2 turn jack...
