Stainless steel coaxial gearboxes (inch) - 1

Gears Nema-Inch Range Stainlessteel Made in Italy Worm gearboxes Coaxial gearboxes Stainless steel motors Worm gearboxes and Coaxial gearboxes Cat.: CT-SSP-I-HM010 Riduttori a vite senza fine e coassiali Patented

Open the catalog to page 1
Stainless steel coaxial gearboxes (inch) - 3

See technical data table. Vedi tabelle dati tecnici. Pag. M-4 Full stainless NEMA motors. Motori completamente in acciaio inox. steel NEMA See technical data table. Vedi tabelle dati tecnici. Paragraph 8 Full stainless steel Riduttori coassiali completamente in acciaio inox. Coaxial gearboxes. See technical data table. Vedi tabelle dati tecnici. Paragraph 7 Full stainless steel Vite senza fine completamente in acciaio inox. Wormgear boxes. IN THIS CATALOGUE Full Stainless steel electric motors Full Stainless steel - Coaxial gearboxes Full Stainless steel - Worm gearboxes

Open the catalog to page 3
Stainless steel coaxial gearboxes (inch) - 4

Full Stainless Steel Housing. Stainless Steel Hollow shaft. output seal(FPM - fkm) with external dust protection lips. Special housing designed to keep adeguate lubrication with low Oil q.ty to avoid internal pressures. O-rings on all closing covers. 100 % Factory pressure leak test. Second Bearing Optional interchangeable right or left hand output shafts available. Life lubricated fully synthetic oil Standard second bearing on motor flange side and two oil seals with vertical motor position. Protective seals cup to stand high pressure cleaning for hollow or extended shaft version. TORQUE...

Open the catalog to page 4
Stainless steel coaxial gearboxes (inch) - 5

7-3 7-5 7-7 7-9 Types / tipi / Tipos I85 2921lb in I45 345 lb in I50 611 lb in I63 1240 lb in 56C 0.18kw 1/4cv 56C 0.25kw 1/3cv 56C 0.37kw 1/2cv 56C 0.55kw 3/4cv 56C 0.75kw 1cv 56C 1.1kw 1 1/2cv 145TC 1.5kw 2cv 184TC 3.75kw 5cv M-4 On page / A pagina / En la página Types / tipi / Tipos 182TC 2.2kw 3cv On page / A pagina / En la página Selection Features Selection guide - fs Guida alla selezione Mounting pos. - Lubrication Pos. di montaggio - lubrificazione 2 - 6 poles selection Selezione 2 - 6 poli Radial - axial loads Carichi radiali e assiali Reversibility Reversibilità Thermal limit...

Open the catalog to page 5
Stainless steel coaxial gearboxes (inch) - 6

ø A pedido, se pueden enviar nuestros productos de acuerdo con las normas ATEX. A richiesta possiamo fornire i nostri prodotti secondo le normative ATEX On request we can deliver our products according to the ATEX Size - Grandezza Tomaño 7-1 P I45 UN I45 I50 I63 I85 Ratio - Rapporto Relaciòn S ø0.750” ø1.000” ø1.125” ø1.500” INCH I45 I50 I63 I85 10 Hub - Mozzo corona Nucleo corona Type - Tipo Tipo Mounting - Montaggio Tipo de montaje See technical data table Vedi tabelle dati tecnici. Ver tabla datos técnicos Motor size Grandezza motore Tamaño motor NEMA W Output shaft Albero lento Eje...

Open the catalog to page 6
Stainless steel coaxial gearboxes (inch) - 7

7-2 1.29 0.91 0.67 257 257 257 QUICK SELECTION / Selezione veloce 80 79 77 2.2 2.2 2.4 01 02 03 RD Ratios Mn code input speed (n ) = 1750 min-1 1 Dynamic efficiency Tooth Module 250.0 175.0 125.0 7 10 14 1 0.75 0.75 202 213 291 1.3 1.2 0.9 n[min2 -1] i P1M [HP] M2M [lb in] f.s. P1R [HP] M2R [lb in] Output Speed Ratio Motor power Output torque Service factor Nominal power Nominal torque 56C - Available NEMA motor flanges W - 345lb in Rightangle - Gear Velocità in entrata Input speed Velocidad de entrada A Select required torque (according to service factor) Seleccionar el par deseado...

Open the catalog to page 7
Stainless steel coaxial gearboxes (inch) - 8

345lb in Stainlessteel - Gear Output shaft Albero di uscita RADIAL AND AXIAL LOADS tab. 2 C) * Power higher than the maximum one which can be supported by the gearbox. Select according to the torque M2R Potenza superiore a quella massima sopportabile dal riduttore. Selezionare in base al momento torcente M2R B) B) QUICK SELECTION / Selezione veloce 80 79 77 67 65 63 59 56 54 49 2.2 2.2 2.4 1.6 2.5 1.8 1.5 1.2 1.0 0.72 01 02 03 04 05 06 07 08 09 10 RD Ratios Mn [mm] code input speed (n ) = 1750 min-1 1 Dynamic efficiency Tooth Module Motor Flange Holes Position Posizione Fori Flangia Motore...

Open the catalog to page 8
Stainless steel coaxial gearboxes (inch) - 10

611lb in Stainlessteel - Gear Output shaft Albero di uscita RADIAL AND AXIAL LOADS tab. 2 Motor Flange Holes Position Posizione Fori Flangia Motore Available on Request without reduction bushing Disponibile a Richiesta senza Bussola di Riduzione Motor Flanges Available C) Flange Motore Disponibili Supplied with Reduction Bushing Fornito con Bussola di Riduzione B) B) 250.0 175.0 125.0 97.2 67.3 48.6 40.7 29.2 25.7 21.9 17.5 7 10 14 18 26 36 43 60 68 80 100 2 1.5 11 0.75 0.5 0.5 0.33 0.33 0.25 0.25 413 432 398 486 485 447 511 414 461 389 450 1.2 1.2 1.4 1.1 1.2 1.4 1.1 1.3 1.1 1.2 1.0 n[min2...

Open the catalog to page 10
Stainless steel coaxial gearboxes (inch) - 12

7-7 Motor Flange Holes Position Posizione Fori Flangia Motore Available on Request without reduction bushing Disponibile a Richiesta senza Bussola di Riduzione Motor Flanges Available C) Flange Motore Disponibili Supplied with Reduction Bushing Fornito con Bussola di Riduzione B) B) 1240lb in Stainlessteel - Gear RD Ratios code Dynamic efficiency 83 81 79 78 75 74 68 66 60 57 52 3.1 3.1 3.1 2.6 2.0 3.2 2.7 2.1 1.5 1.3 1.1 BBBBBBBBBBB Tooth Module input speed (n ) = 1750 min-1 1 Mn[mm] n[min2 -1] i P1M [HP] M2M [lb in] f.s. [HP] [lb in] Output Speed Ratio Motor power Output torque Service...

Open the catalog to page 12
Stainless steel coaxial gearboxes (inch) - 14

2921lb in Stainlessteel - Gear Output shaft Albero di uscita RADIAL AND AXIAL LOADS tab. 2 Motor Flange Holes Position Posizione Fori Flangia Motore Available on Request without reduction bushing Disponibile a Richiesta senza Bussola di Riduzione Motor Flanges Available C) Flange Motore Disponibili Supplied with Reduction Bushing Fornito con Bussola di Riduzione B) B) RD Ratios code Dynamic efficiency 88 80 78 79 75 71 66 65 53 4.23 4.2 4.5 3.4 4.7 3.5 2.7 2.1 1.5 01 02 03 04 06 07 09 10 12 Tooth Module input speed (n ) = 1750 min-1 1 Mn [mm] n[min2 -1] i P1M [HP] M2M [lb in] f.s. [HP] [lb...

Open the catalog to page 14
Stainless steel coaxial gearboxes (inch) - 16

Flange Fully modular to IEC B14 and Compact integrated motor. NEMA C flange Two oil seals on request Oil seals Stainless steel Output shaft With well proportioned bearings Smooth stainless steel housing Lubricated for life with synthetic oil with operative range from -15° to +130°C Gears Hardened and ground gears. Standard FPM (fkm) seals A modular and compact product Stainless steel in line gearboxes

Open the catalog to page 16
