Connectors M 16 / Housing Cable-Ø Panel Connector with built in Cable Strain Relief Part Number Rear mounting, single hole mounted 2 – 7 mm (.08 – .28“).........7.852.300.000 5 – 9 mm (.20 – .35“).........7.852.400.000 46,2 M 16 x 0,75 20,3 Including jam nut PG 11 15 22 Panel hole 21 Ø 18,6 + 0,1 Contacts and inserts page 22 • Assembly instructions page 34 / 35 Cable-Ø Panel Connector with built in Cable Strain Relief Part Number Rear mounting, M 2,5 x 4 single hole mounted 2 – 7 mm (.08 – .28“).........7.847.300.000 5 – 9 mm (.20 – .35“).........7.847.400.000 46 20 15 15 M 16 x 0,75 31 15 M 2,5 Panel hole 20 Ø 16,2 + 0,1 Contacts and inserts page 22 • Assembly instructions page 34 / 35 Type max. 10 mm max. 6 mm Panel Connector, Male Thread, Front Mounting Part Number 4 x holes Ø 2,7 mm (.11“) ..7.840.000.000 Flange 20 x 20 mm 25 19,8 20 15 M 16 x 0,75 Ø 2,7 23,5 4 x holes Ø 2,7 mm............7.840.100.000 Flange 25 x 25 mm Ø 2,7 Panel hole Panel hole Ø 15 + 0,1 Ø 20 + 0,1 Contacts and inserts page 22 • Assembly instructions page 38 Type Panel Connector, Male Thread, Front Mounting Part Number Short version 4 x holes Ø 2,7 mm (.11“) ..7.840.200.000 Flange 20 x 20 mm M 16 x 0,75 20 15 26 12 Ø 2,7 14 20 Panel hole Ø 15 Contacts and inserts page 22 • Assembly instructions page 38 Ø 15,2 + 0,1 Dimensions and specifications may be changed without prior notice 19
