HSK cable glands for special applications
HSK-XL
G
RoHS
Material
Nickel plated brass
Seal
Buna-N
O-Ring
Buna-N
Protection
IP 68
Operating Temperature
- 20 °C – 100 °C (- 4 °F – 212 °F)
Advice:
- Other sealing material e.g. Silicone upon request
- Stainless steel on request
AG
mm
G
G
G
G
G
G
G
G
2 1/2”
2 1/2”
3”
3”
4”
4”
4”
4”
GL
mm
H
mm
mm
Number
48 –55
53 –60
58 –65
63 –70
68 –75
73 –80
78 –85
83 –90
18
18
18
18
22
22
22
22
42
42
42
42
52
52
52
52
80
85
90 / 95
100
100 / 120
110 / 120
110 / 120
120
1.106.5200.01
1.106.5201.01
1.106.3000.01
1.106.3001.01
1.106.4000.01
1.106.4001.01
1.106.4002.01
1.106.4003.01
Accessories see page 71
Dimensions and specifications may be changed without prior notice
