Text version of the page
HSK cable glands for special applications
HSK-MINI
Metr., PG
M
Material
Nickel plated brass / 1.4305
RoHS
Seal ring
TPE / FPM
O-Ring
Buna-N / FPM
Protection
IP 68
Operating Temperature - 20 °C – 100 °C (- 4 °F – 212 °F) (Buna-N / TPE)
- 25 °C – 200 °C (- 13 °F – 392 °F) (FPM)
Advice:
- Other sealing material e.g. Silicone upon request
- Other thread pitches on request
- Stainless steel 1.4404 on request
AG
HSK-Mini EMV
AG
HSK-Mini
H
GL
H
GL
AG
mm
GL
mm
H
mm
mm
Number
Buna-N / TPE
Number
FPM
2 – 3,2
2 – 4,5
3–5
4–6
6
3,5
6
6
10
14,3
13
14
8
11
11
12
1.106.0601.50
1.112.0801.01
1.106.0801.50
1.106.1001.50
1.106.0600.55
PG 7
2 – 4,5
3,5
14,3
11/15
1.112.0708.01
HSK-Mini elongated
M 8 x 1,25
M 10 x 1,5
3–5
4–6
10
10
13
14
11
12
1.106.0801.30
1.106.1001.30
HSK-Mini EMV
M 8 x 1,25
M 10 x 1,5
3–5
4–6
6
6
13
14
11
12
1.119.0800.50
1.119.1000.50
HSK-Mini INOX
M 8 x 1,25
M 10 x 1,5
3–5
3–5
6
6
13
14
11
12
1.129.0800.50
1.129.1000.50
M
M
M
M
6x1
8 x 0,75
8 x 1,25
10 x 1,5
1.106.0800.55
1.106.0800.35
1.106.1000.35
Accessories see page 71
Dimensions and specifications may be changed without prior notice
49
