HSK-standard cable glands HSK-K NPT RoHS Material Polyamide V0 according to UL 94 Seal Buna-N IP 68 – 10 bar / IP 69K (NEMA 6 – 150 PSIG) Protection within the specified clamping range, only with optional O-Ring Operating Temperature in black color Colors - 40 °C – 100 °C (- 40 °F – 212 °F) grey (RAL 7035), black (RAL 9005), blue (RAL 5012) for the intrinsic safety “i” AG Advice: - With additional pre-assembled O-Ring upon request - Please find suitable O-Ring on page 86 - Other sealing material e.g. Silicone upon request - Other colors on request H GL AG mm 3/8” NPT 3/8” NPT 1/2” NPT 1/2” NPT 1/2” NPT/16 1/2” NPT/16 3/4” NPT 3/4” NPT 1” NPT 1” NPT 1 1/4” NPT 1 1/4” NPT 1 1/2” NPT 1 1/2” NPT 4 2 6 5 10 7 13 9 18 13 18 13 22 20 – – – – – – – – – – – – – – 8 6 12 9 14 12 18 16 25 20 25 20 32 26 GL mm H mm mm Number grey Number black Number blue 15 15 13 13 13 13 14 14 19 19 16 16 20 20 22 22 27 27 28 28 31 31 39 39 39 39 48 48 19 / 22 19 / 22 24 24 27 27 33 33 42 42 42 / 46 42 / 46 53 53 1.209.3800.70 1.209.3800.71 1.209.1200.70 1.209.1200.71 1.209.1216.70 1.209.1216.71 1.209.3400.70 1.209.3400.71 1.209.1000.70 1.209.1000.71 1.209.5400.70 1.209.5400.71 1.209.6400.70 1.209.6400.71 1.209.3801.70 1.209.3801.71 1.209.1201.70 1.209.1201.71 1.209.1217.70 1.209.1217.71 1.209.3401.70 1.209.3401.71 1.209.1001.70 1.209.1001.71 1.209.5401.70 1.209.5401.71 1.209.6401.70 1.209.6401.71 1.209.3802.70 1.209.3802.71 1.209.1202.70 1.209.1202.71 1.209.1218.70 1.209.1218.71 1.209.3402.70 1.209.3402.71 1.209.1002.70 1.209.1002.71 1.209.5402.70 1.209.5402.71 1.209.6402.70 1.209.6402.71 Accessories see page 71 Dimensions and specifications may be changed without prior notice 19
