| Hose & Reel PRODUCTS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Gas Welding Reels Manual (MX) or Power Rewind | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
| MX chain drive crank rewind or powered by a compressed air or hydraulic motor. MX rewind reels supplied with a Pinion brake. Power reels not supplied with a brake. Standard inlets 90° ball bearing swivel joints with 1/2" female BSPT threads. Standard outlets are male 9/16"-18 threads. Right hand for oxygen, left hand for gas. Rollers may be purchased. Specify roller position (mounting brackets are necessary). Pressures up to 21 bar. Temperatures from -40°C to +93°C. Type of gas used MUST be specified. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Notes: 1. Specifications subject to change. 2. Upon request, reels can be supplied with drum lengths other than shown and with disc sizes in other diameters. 3. Dimension "F" is the overall length of standard model reels. On crank rewind models, the dimension shown is with the crank in rewind position. Reels require 2" clearance to remove crank handle. 4. When ordering power rewind models replace MX prefix with: A = Air Rewind HD = Hydraulic Rewind 5. Accessory seperated. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
| 2400 - Welding Reels to handle twin 1/4" through 3/8" welding hose | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Series MX 2400 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
