Workpiece management Fixturing Systems by HIRSCHMANN

Fixturing System 4000 for Wire EDM - 16419 Holds tightly, changes quickly, always wins.

mm

High precision and versatility weights up to 150 kg (330 lbs)

mm

Solid referencing, not influenced by high flushing pressures

mm

Automation ready

mm

Minimal contact of the systems reference planes

mm

0,002 mm (0.00008 ) repetitive accuracy (on-off, position toposition)

mm

Rust-proof

mm

Not affected by dust

mm

Not affected by heat. The coordinate position is never lost, even in case of an extreme temperature rise (no flexing).

mm

Compatible to all Fixturing Systems by HIRSCHMANN

mm

Workpiece palletizing incorporating automatic or manual change

mm

High repetitive accuracy from set-up to machine

mm

Easy adjustment of small and large workpieces

mm

Simple and precise workpiece handling
