T Nuts
Hepco T nuts are manufactured in high grade steel supplied chemically blacked and are designedto fit the T slots of the Hepco construction beam. Three types are available, the flush type (HTN25) for attachment of customers own components, the location type (HTN25-L) which locates into the keyways of the Hepco backplates (see page 12), and the adjustment type (HTN25-A) required for the system alignment facility (see page 12). All T nuts are supplied with a retaining spring clip to prevent loss of position. Approximate weights of T nuts are as follows: HTN25=25g, HTN25-L=38g, HTN25-A=35g.
Ordering Details
Simply state the quantity and part number required.
Example:
10 x HTN25-L
Hepco pinions are made from high grade steel with hardened teeth for maximum wear resistanceand are supplied natural finish. Two types of pinion are available, the bored type (HP25) for customers own shaft and the shaft type with integral shank (HP25-S) supplied in two lengths and which may be reworked to customersdrawing either by customers themselves or by Hepco. Approximate weights of pinions are as follows: HP25=400g, HP25-S-L100=800g, HP25-S-L180=1100g.
Ordering Details
Simply state the quantity and part number required and in the case of the shaft pinion include suffix
(L100) or (L180) according to length required.
21
Example:
1 x HP25-S-L180
Carriage Plates
Due to the wide variety of requirements, carriage plates are manufactured tocustomers own drawing to specified shape and size. Carriage plates are machined all over and are available in either steel or aluminium in the following thicknesses: 11mm, 14mm, 17mm, 20mm. Dimensions and components, shown dotted, serve as a design aid.
Note:
0.5 on dimensions shown, unless a specific datum reference to the centre of the industrial slide is important. Drilling centres to suit precision grade slides/tracks are shown in italics above those in standard text for commercial grade. For customers making their own carriage plates, please note that drilling centres are not critical and may be Ordering Details
==
= Please submit a drawing of your requirements. ❉■
▲ To suit customers requirements and for variable spacing of single edge V slides To suit double edge V slide
To suit double edge V slide/ narrow flat track with V bearingswith bearing blocksor wide flat track with
track rollers
