Cap Wipers

C CC

ap Wipers form an enclosure around a V bearing assembly when engaged with a V industrial slide. They provide constant lubrication thereby greatly increasing the life of a system; they prevent ingress of debris and improve operational safety and appearance. Lubrication is carried out by means of oil impregnated felt wipers spring loaded onto the slide. The internal cavity is filled with grease via the lubrication point provided thus ensuring lubrication at the slide/bearing contact face and recharging of the felt wipers as the grease partially liquefies under operation.Cap wipers are manufactured in two parts from impact resistant glass filled acetal weighing a total of ~170 grams. The removable side permits access to both the hexagon flange and end socket of the bearing assembly (see pages 14-16) thus allowing easy adjustment of the system without disassembly.Cap wipers may be attached either via the clearance slots using the fixing screws provided, or via the tapped holes in the underside.The fixing hole position for the cap wiper relative to the V slide is the same as for the V bearing assemblies, details of which may be found on the assembled system pages 7 to 9.

18

Notes:
Inserts in the underside provide a M5 x 0.8 thread x 9 long. A deep cavity behind the inserts enables long screws to be accommodated. When utilising this alternative fixing method it is recommended that 7mm Ø holes be drilled in the mounting plate to provide adjustment.Replenish lubricant as necessary using a NLGI No. 1 consistency grease. Male grease connector part no. CSCHF4034 or complete gun is available from Hepco if required. Lubrication interval depends upon length of stroke, duty and environmental factors but is typically 500km of linear travel.1.2. Ordering Details
Simply specify the quantity and part numbers required. Example:
4 x CW64Cap wiper1 x CSCHF4034Male grease connector
