7 BEK Bearing Housing - Fixed End Ballscrew Diameter 6 8 10 12 14 Part No. – BEK8 BEK10 BEK12 BEK14 A 20 23 24 24 B 42 52 70 70 b 21 26 35 35 C 25 32 43 43 D 20 24 24 24 E 18 25 36 36 Standard housed bearing units are not available. F 30 38 52 52 G 13 17 25 25 ØK 5.5 6.6 9 9 ØL 9.5 11 – – M 11 12 – – S 27 31.3 35.4 35.3 T 22 25 27 27 U 1.5 1.3 – – ØP 6 8 10 12 Q M6x0.75 M8x1 M10x1 M12x1 R 12 14 16 19 The HepcoMotion® BEK bearing housings are made from chemically blackened steel and contain a pair of matched angular contact bearings to provide accurate radial and axial location for the ballscrew. On installation, the locking nut should be fully tightened and locked in place using the grub screw. The standard ballscrew machined ends (see page 9) fit into these housings. To suit ballscrew end machining figure A A B A B B b±0.02 D E F R A/F ØP A T S Q G±0.02 = = ØK C A B A B b±0.02 B G±0.02 D E F R A/F = = ØK ØL M T A U S Q ØP C Section A-A Section A-A Section B-B Section B-B BEK12 & BEK14 BEK8 & BEK10 Grub screw Grub screw
