Half-bridge strain gage
1000 Ω ,grid distance* 13.2 mm
Dimensions :- grid length3.2 mm - grid width4.2 mm - overall length19 mm - overall width6 mmTechnical data
µ m - material:Constantan - thickness:3.8 Measuring grid Carrier µ m ±2 µ m- cover thickness:25 - material:Polyetheretherketone (Peek) - base thickness:25 µ m ±2 µ m Connections - integrated solder pads Resistance 1000 Ω ±0.3%balancing resistor of 12 Ω Thermal expansion coefficient α for aluminum 23 x 10Actual size
-6 /K*distance between middle of the two grids
Matched to AluminumMatched to Steel
Creep CodePart No.Part No.
Open Faced GridMatched to AluminumMatched to Steel
Creep CodePart No.Part No.
3sK-216.51-2242Encapsulated Grid Stick-on option available on requestOther creep codes available on request
