Single-shear strain gage
1.9 mm,350 Ω
Dimensions :- grid length1.9 mm - grid width3.2 mm- overall length9.4 mm- overall width4.4 mmTechnical data
µ m - material:Constantan foil - thickness:5 Measuring grid Carrier µ m ±10 µ m- cover thickness:25 - material:phenolic resin, glass-fiber reinforced - base thickness:35 µ m ±8 µ m Connections - integrated solder pads Resistance 350 Ω ±0.3% Thermal expansion coefficient α for steel 10.8 x 10-6 /K
Actual size Matched to AluminumMatched to Steel
Creep CodePart No.Part No.
Open Faced GridMatched to AluminumMatched to Steel
Creep CodePart No.Part No.
6.5sK-216.61-2041Encapsulated Grid Stick-on option available on requestOther creep codes available on request
