SG accessories bonding material

Cold curing adhesives

Cold curing adhesives are easy to use and can be processed at minimum cost and eff-ort since they harden under normal ambient conditions. If they feature short curing times they are also called superglue. The preferred eld of application is in experi- mental stress analysis. However, if the temperature around the measuring point is hig- her than about 80C, we recommend to use a hot curing adhesive or a heat resistant, cold curing epoxy resin adhesive (280).

Spot weld joints

Spot weld joints are only possible with the special strain gage of type LS 31, and if the test object is of a weldable material. This method is particularly suitable for applica- tions where the cleanliness required for bonding cannot be guaranteed. Hardly any pre- parations are necessary and the installer needs very little previous experience. However, it is essential to follow the process instructions supplied with the strain gages.

Storage CuringCuringContact pressureTemperature limitsDelivery quantitytimetemperatureperiod

(N/mm

)lowerupperupperabsolute

relative

6 months5C

10 minutesthumb pressure– 55C+ 100C+120C10 mlat– 15C:20C1 minute(temporarily almost unlimited30C0.5 minutes- 70C) 1 year0C60 minutesthumb pressure– 200C+ 60C+ 80Ccomponent20C10 minutesA= 0.1 kg35C2 minutesB = 80 mlother quantitiessee price list1 year at+ 4CRT . . . 95C8 h . . . 1 h0.05 . . . 2.0– 70C+ 200C+ 280C6 doublepouches 10 g = 60 g6 months95 . . . 205C5 h . . . 0.5 h0.1 . . . 0.5-270C+ 260C+ 310CcomponentA = 60 mlB = 30 ml1 year95 . . . 200C16 h . . . 0.5 h0.1 . . . 1.5– 240C+ 250C+ 315C5 doublepouches 10.5 g = 52.5 g

zero-point related measurement

non zero-point related measurement

curing conditions: relative humidily between 30-80

3 Strain Gages and Accessories79
