SG / Y series strain gage chains
KY7x
Stock types
Vriants
No­minal reSs-tance
Dmensions (mm) 1 inch = 25.4 mm
Max. perm. effective industrial bridge excitation voltage
Solder terminals
Strain gage chain
comprisng 10 measuring grids with common connection ( in parallel, vertical to the measuring chain axis alternatingly)
and 1 compensating strain gage
Temperature response matching at customers choice, see page 20
Measuring Measuring
Pitch
grid
grid carrier
Stee
Aluminum
Others
a b c d t
V
£2
Illustrations show actual sze
(Ptch t in mm)
1-KY7x-2/120
120
1.3
1.5
6
22.8
2
2.5
1
b
T
1
t c
T
■ I
1
"ill
Contents per package: 5 pes
Strain gages and Accessories
41
