17274 - Hayward Flow Control IPG Catalog.indd table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:5.00pt "Arial", sans-serif; } .font1 { font:5.60pt "Arial", sans-serif; } .font2 { font:9.00pt "Arial", sans-serif; } .font3 { font:12.00pt "Arial", sans-serif; } .font4 { font:6.00pt "Impact", sans-serif; } .font5 { font:5.00pt "Tahoma", sans-serif; } .font6 { font:7.00pt "Tahoma", sans-serif; } .font7 { font:8.00pt "Tahoma", sans-serif; } .font8 { font:10.00pt "Tahoma", sans-serif; } .font9 { font:11.00pt "Tahoma", sans-serif; } .font10 { font:15.00pt "Tahoma", sans-serif; } DAB Séries True Union Diaphragm Valves 1/2" TO 2" PVC, CPVC, PP AND PVDF key features • PVC, CPVC, PP and PVDF • Position Indicator • Ergonomie Handwheel • Choice of FPM, EPDM or PTFE Diaphragms* options • Electric or Pneumatic Actuation • PVDF Vapor Barrier** materials • PVC Cell Class 12454 per ASTM D1784 • CPVC Cell Class 23447 per ASTM D1784 • PP per ASTM D4101 • PVDF • FPM, EPDM and PTFE O-Ring Seals * All PTFE diaphragms are EPDM backed ** PVDF Vapor Barrier available with EPDM and PTFE diaphragm only TEOHNIOAL INFORMATION exploded view j sélection chart size material end connection diaphragm seals pressure rating 1/2" - 2" (DN15 - DN50) PVC or CPVC Socket and Threaded PFTPFEoErPPVrDF FPM or 150 PSI @ 70°F S™ EPDM Non-Shock PP or PVDF Threaded WWW.HAYWARDFLOWCONTROL.COM • 1.888.429.4635 39
