17274 - Hayward Flow Control IPG Catalog.indd table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:9.00pt "Microsoft Sans Serif", sans-serif; } .font1 { font:11.00pt "Microsoft Sans Serif", sans-serif; } .font2 { font:4.40pt "Tahoma", sans-serif; } .font3 { font:5.00pt "Tahoma", sans-serif; } .font4 { font:7.00pt "Tahoma", sans-serif; } .font5 { font:8.00pt "Tahoma", sans-serif; } .font6 { font:11.00pt "Tahoma", sans-serif; } .font7 { font:15.00pt "Tahoma", sans-serif; } .font8 { font:31.00pt "Tahoma", sans-serif; } ©IH AYWARD SB Séries Simplex Basket Strainers 1/2" TO 4" PVC, CPVC, GFPP AND EASTAR® key features • PVC, CPVC, GFPP and Eastar • Ergonomie Hand-Removable Cover • In-Line or Loop Connections • External Cover Threads • Integral Flat Mounting Bases • NSF / ANSI 61 Listed options • Stainless Steel, Monel® Hastelloy® and Titanium Strainer Baskets • Pressure Differential Gauge and Switch • Baskets Available with Perforated or Mesh Liners materials • PVC Cell Class 12454 per ASTM D1784 • CPVC Cell Class 23447 per ASTM D1784 • GFPP Cell Class 85580 per ASTM D4101 • Eastar • FPM and EPDM O-Ring Seals TEOHNIOAL INFORMATION exploded view selection chart size material end connection seals pressure rating 1/2" - 4" (DN15 - DN100) PVC, CPVC and GFPP Socket, Threaded or Flanged FPM or EPDM 150 PSI @ 70°F Non-Shock Eastar* 100 PSI @ 70°F Non-Shock * End connections and assembly nuts are PVC WWW.HAYWARDFLOWCONTROL.COM • 1.888.429.4635 101
