'G'Approx (Compressée! Length)

Cable Gland/ConnectorType

710

c^Dus

Explosion Proof

Compound

CABLE GLAND/CONNECTOR SELECTION TABLE

Application

• Outdoor or Indoor use.

• For use with non-armoured cable, as permitted by the NEC.

• See technical section of the catalogue for installation rules and régulations.

Size Réf.

Entry Thread Size

Cable Acceptance Détails

'G'

Hexagon Dimensions

Inner Jacket/Cores

Outer Jacket 'B'

'D'

Max. Over Cores

'E'

Max. Inner Jacket

Max. No. Of Cores

NPT

Std./ Option

Metric

Across Flats

Across Corners

Min.

Max.

'A"

M20²

0.35"

0.39"

0.22"

0.47"

2.81"

0.94"

1.09"

'A"

M20²

0.35"

0.39"

0.37"

0.63"

2.81"

0.94"

1.09"

>A"IVa"

M20

0.43"

0.64"

0.49"

0.81"

2.84"

1.18"

1.36"

Va"I\"

M25

0.64"

0.93"

0.66"

1.02"

2.95"

1.42"

1.64"

171/"

M32

0.86"

1.23"

0.87"

1.30"

3.1 1"

1.81"

2.09"

VU'IVA'

M40

1.04"

1.59"

1.10"

1.61"

3.26"

2.17"

2.50"

27l/₂"

M50

1.46"

1.96"

1.42"

2.07"

3.36"

2.56"

2.96"

2/272"

M63

1.88"

2.55"

100

1.81"

2.57"

3.56"

3.15"

3.64"

372/2"

M 75

2.32"

2.98"

120

2.24"

3.07"

3.76"

3.74"

4.31 "

'H' size cable gland/connector available. Contact Hawke International for further détails.

3/"

M90

2.79"

3.12"

3.07"

3.52"

3.54"

4.18"

4.84"

c c o

c o

■Si 3 o U o

Features

• Provides a barrier seal between the individual insulated conductors within the cable and prevents entry of the products of an explosion into the cable.

• Assembly of the cable gland/connector compresses and distributes the compound evenly to effect a barrier seal at the point of entry into the enclosure.

• Provides an outer déluge seal to prevent moisture ingress to the cable armour and enclosure.

Déluge seal is coloured red to indicate Hazardous Locations product. Provides a cable rétention and low smoke and fume, zéro halogen seal onto the cables outer jacket.

²Sizes Os and O are available with an M16 thread size. For O size with M16 thread, the maximum cable inner sheath diameter is 0.43".

General Information

AN dimensions in inches (except* where dimensions are in millimètres). Os - F size metric entry threads are 1.5mm pitch as standard with 15mm length of thread. For G size cable glands and above, a 2mm pitch is supplied as standard with a 20mm length of thread (1.5mm pitch with 15mm length of thread can be supplied) please specifiy when ordering.

Two part sealing compound and assembly instructions are supplied with the cable gland/connector.

Assembly instruction data sheet No. A.I. 3 16. For sizes Os to F. Assembly instruction data sheet No. A.I. 337. For size H. Accessories including locknuts, sealing washers, serrated washers, earth tags, shrouds, adaptors and reducers available. See pages 44 - 48.

Technical Data

• UL Listed for use in Class I, Division 2, Gas Groups A, B, C and D.

• UL Listed for use in Class I, Zone 2, Gas Groups MA, MB and IIC.

UL listed AExd IIC and AExe II Class I.Zone 2.

• Construction and test standards

^ C®US ^UL Listed hazardous

locations in USA and Canada. E84940.

• IP66, IP67 and IP68 (30 mètres for 7 days) ingress protection to IEC 60529, EN60529 and NEMA 4X.

• DTS01 déluge tested by ITS.

• Operating température range -50°C to +60°C as standard.

Materials & Finishes

The 710 cable gland/connector is manufactured as standard in brass, stainless steel and aluminium.

NPT entries, nickel plated as standard. Full nickel plating available.

Cable Gland/Connector Ordering Examples Cable Gland/ConnectorType/Size/Thread

e.g. 7I0/C/I" NPT
