HRSCD

Z3552/.../16

Thermofühler

Thermocouple

Thermocapteur

+

Fe-CuNi, Type J

Z3552/.../16 © weiß/white/blanc _O rot/red/rouge_


	// max. 200° £ J II \ ^S ^^Si........u.u^......mW>MMAWj ' ' 1 ~			o
	a- 1500	—> <— 25 ±2		- [ \ * l₂ ±1

"X"

"X"


	für /for /pour \| Z3500/...	für /for /pour Z3501/...	d3	l2	b1	Amerika	Nr./No. America	EDV-Nr.
	r26x13x 62/...	26x13x 62/...	1,5	100	2,1	16	Z3552/1,5x100x2,1/16	587676
	32x16x 62/...	32x16x 62/...
	26x13x 82/...	26x13x 82/...
	32x16x 82/...	32x16x 82/...
	40x19x 62/...	40x19x 62/...
	40x19x 82/...	40x19x 82/...
	26x13x102/.	26x13x102/...		140			Z3552/1,5x140x2,1/16	587678
	32x16x102/.	32x16x102/...
	26x13x122/.	26x13x122/...
	32x16x122/.	32x16x122/...
	40x19x102/.	40x19x102/...
	40 x19x122 /.	40x19x122/...
	40x19x142/.	40x19x142/...		200			Z3552/1,5x200x2,1/16	587680
	40x19x182/.	40x19x182/...
	50x22x 62/.	-		100	3		Z3552/1,5x100x3 /16	587682
	50x22x 82/.	-
	50x22x102/.	-		140			Z3552/1,5x140x3 /16	587684
	50x22x122/.	-
	50x22x142/.	-		200			Z3552/1,5x200x3 /16	587686
	50x22x182/.
	50x22x232/.			250			Z3552/1,5x250x3 /16	587688

18
