RS 42 & RS 51 & RS 65 & Super-Precision RS 42 Super-Precision RS 51 Super-Precision RS 65 Bidirectional Turret Top Plate ESA Tool Confi guration 12 Station 12 Station 12 Station Square Shank Tool Size (Max.) 25mm (1”) 25mm (1”) 25mm (1”) Round Shank Tool Size (Max.) 32mm (1
1 /
4 ”) 32mm (1
1 /
4 ”) 32mm (1
1 /
4 ”) Indexing Time (Station-to-Station) .35 Second .35 Second .35 Second ESA Live Tooling Option—All Stations
2 Tool Shank Diameter w/ER25 Collets 2 to 16mm (.062 to .625”) 2 to 16mm (.062 to .625”) 2 to 16mm (.062 to .625”) Power Rating
1 3.7kW (5hp) 3.7kW (5hp) 3.7kW (5hp) Torque Rating
1 23.6Nm (17.4ft-lb) 23.6Nm (17.4ft-lb) 23.6Nm (17.4ft-lb) Speed Range (1-rpm Steps) 80 to 8,000 80 to 8,000 80 to 8,000 VDI 30 Tool Confi guration Option
2 12 Stations 12 Stations 12 Stations Square Shank Tool Size (Max.) 25mm (1”) 25mm (1”) 25mm (1”) Round Shank Tool Size (Max.) 40mm (1
1 /
2 ”) 40mm (1
1 /
2 ”) 40mm (1
1 /
2 ”) Indexing Time (Station-to-Station) 0.1 Second 0.1 Second 0.1 Second VDI 30 16-Station Tool Confi guration Option
2, 4 16 Stations 16 Stations 16 Stations VDI 30 Live Tooling Option—All Stations
2 Tool Shank Diameter w/ER25 Collets 2 to 16mm (.062 to .625”) 2 to 16mm (.062 to .625”) 2 to 16mm (.062 to .625”) Power Rating at Tool Tip
7 3.7kW (5hp) 3.7kW (5hp) 3.7kW (5hp) Torque Rating at Tool Tip
8 23.6Nm (17.4ft-lb) 23.6Nm (17.4ft-lb) 23.6Nm (17.4ft-lb) Speed Range (1-rpm Steps) 80 to 8,000 80 to 8,000 80 to 8,000 Conventional Hardinge Top Plate T-Style Turret Top Plate Option
2 (Inch or Metric) 12 Stations 10 or 12 Stations 10 or 12 Stations Square Shank Tool Size (Max.) 20mm (
3 /
4 ”) 25mm (1”) 25mm (1”) Round Shank Tool Size (Max.) 32mm (1
1 /
4 ”) 40mm (1
1 /
2 ”) 40mm (1
1 /
2 ”) Indexing Time (Station-to-Station) .35 Second .35 Second .35 Second Sub Spindle Option
1, 2, 9 Spindle Confi guration (ANSI) A2-5, 16C A2-5, 16C A2-5, 16C Round 16C Collet (Through Capacity) 42mm (1.625”) 42mm (1.625”) 42mm (1.625”) Jaw Chuck Size 150mm (6”) 150mm (6”) 150mm (6”) Step Chuck (Gripping Capacity) 152.4mm (6”) 152.4mm (6”) 152.4mm (6”) Power Rating @ 1,500-rpm Base Speed 7.5kW (10hp) 7.5kW (10hp) 7.5kW (10hp) Torque Rating 47.7Nm (35ft-lb) 47.7Nm (35ft-lb) 47.7Nm (35ft-lb) Speed Range (1-rpm steps) 60 to 6,000 60 to 6,000 60 to 6,000 Travel (Max.)
10 603.3mm (23.75”) 603.3mm (23.75”) 603.3mm (23.75”) Traverse Rate (Max.) 38m/min (1,500ipm) 38m/min (1,500ipm) 38m/min (1,500ipm) Hydraulic Tailstock Option
2 MT 4 MT 4 MT 4 Part Length (Max.) 609.6mm (24.00”) 609.6mm (24.00”) 609.6mm (24.00”) Travel (Max.) 546.1mm (21.50”) 546.1mm (21.50”) 546.1mm (21.50”) Traverse Rate (Max.) 7.6m/min (300ipm) 7.6m/min (300ipm) 7.6m/min (300ipm) Hydraulic Applied Force (Min. to Max.) Power Supply Requirement Miscellaneous 129 to 320daN (290 to 720lb) 280 to 700daN (630 to 1,570lb) 280 to 700daN (630 to 1,570lb) Machine Dimensions
11 230v/3 Phase/99FLA 230v/3 Phase/112FLA 230v/3 Phase/135FLA Coolant Tank Capacity 189liter (50gal) 189liter (50gal) 189liter (50gal) Coolant Pressure 12.9bar (187psi) 12.9bar (187psi) 12.9bar (187psi) Coolant Flow Rate 25.5L/min (6.75gpm) 25.5L/min (6.75gpm) 25.5L/min (6.75gpm) High-Pressure Thru-Tool Coolant Option 98.95bar (1,000psi) 98.95bar (1,000psi) 98.95bar (1,000psi) Length 2991.6mm (117.78") 2991.6mm (117.78”) 2991.6mm (117.78”) Length with Chip Conveyor Option 4190.8mm (164.99") 4190.8mm (164.99”) 4190.8mm (164.99”) Depth 2289.6mm (90.14") 2289.6mm (90.14”) 2289.6mm (90.14”) Height 1973.8mm (77.71") 1973.8mm (77.71”) 1973.8mm (77.71”) Weight (Approx.) 6532kg (14,400lb) 6798kg (14,986lb) 6979kg (15,386lb) Shipping Weight (Approx.) 6804kg (15,000lb) 7070kg (15,586lb) 7206kg (15,886lb)
