Communication Hardware Communication Hardwar e

R-358 Computer Interface A-908 IR ReceiverA-910 (900 MHz and 2.4 GHz) R-358 Computer Interface A-908 IR Receiver A-910 (900 MHz and 2.4 GHz)

Computer interfaces and new wireless receiver technology Computer interfaces and new wireless receiver technology

R-358 Computer Interface

""). An AC adapter/charger is provided, and the unit features LED charging and power indicators. Also available is a standard-resolution version (.0001 The R-358 interface can support two single-axis or dual-axis targets, (a 10-foot splitter cable is available as an accessory for operating dual-axis targets) or one 4-axis target.

A-910 Radio Transceiver/Hub (900 MHz and 2.4 GHz)

Hamar Laser’s A-1519/1520 Type II Universal Wireless Targets incorporate a built-in radio transceiver, available in 900 MHz or 2.4 GHz ISM band. Operating through the A-910 Radio Transceiver/Hub, up to 99 Type II Targets may be connected as a Target System Group, and up to ten Target System Groups consisting of 99 targets per group may be used at one time. Power is supplied by a 3.5 volt lithium ion, rechargeable battery or by the computer’s USB port. When connected to the USB port, the battery charges automatically. For fewer than four targets, the A-910ZB is a very small, USB-powered 2.4 GHz radio transceiver that can read up to four targets simultaneously.The 900 MHz model has an indoor range of 300 feet (91meters) and the 2.4 GHz model has an indoor range of 600 feet (1.83 meters). Data transmission is 4 mW and 50 mW respectively.

A-908 IR Receiver

The A-908 IR Receiver is a wireless data receiver that operates with Hamar Laser’s wireless targets. It uses an infrared, frequency-modulated receiver that does not interfere with radio-based communication systems. The receiver has a range of 10-100 feet, depending on the target used, and an acceptance range of ±85 degrees. The unit is powered by a replaceable 9V battery. The R-358 computer interface provides exceptionally high accuracy (.00004 resolution) for downloading target data to Hamar Laser’s alignment software. The interface attaches to the computer with an RS-232 cable, and it is powered by a lithium ion battery for long life and usage.
A-908 IR Receiver A-910 Transceiver/Hub (900 MHz/2.4 GHz) R-358 Computer Interface 5 Ye Olde Road, Danbury, CT 06810 E-mail: sales@hamarlaser.com • •
