| | SAG-8E | SAQ-8E | SNB-8E | SAG-12E | Belt application | |
| | | | | | Sheet feeder/layboy | |
| | | | | | Sheet folder | |
| | | | | | Folder of web-fed printing machine | |
| | | | | | Finishing systems/bookbinding | |
| | | | | | Newspaper production (printing- and mailroom equipment) | |
| | | | | | Sheeter/crosscutter | |
| | • | • | • | • | Corrugated cardboard production | |
| | • | | | • | Folder-gluer machine | |
| | | | | | Tubewinder | |
| | | | | | Tissue and diaper production | |
| | • | • | • | • | Paper and cardboard converting, various kind of applications | |
| | • | • | • | • | | |
| | • | • | • | • | Cardboard conveying | |
| | | | | | Feeder belt/pick-off belt | |
| | | | | | Driving belt | |
| | • | • | • | • | | |
| | | | | | Incline belt | |
| | | | | | Power turn belt | |
| | | | | | Product construction/design | |
| | PVC | PVC | PVC | EPT | Conveying side (Material) | |
| | Grip str. | Quadrill | Sand finish | Grip str. | Conveying side (Surface) | |
| | \dhesive | Adhesive | Non-adh. | Adhesive | Conveying side (Property) | |
| | nthracite | Anthracite | Anthracite | Anthracite | Conveying side (Color) | |
| | PET | PET | PET | PET | Traction layer (M aterial) | |
| | 2 | 2 | 2 | 2 | | |
| | PET | PET | PET | PET | Running side/pulley side (Material) | |
| | Fabric | Fabric | Fabric | Fabric | Running side/pulley side (Surface) | |
| | | | | | Running side/pulley side (Property) | |
| | 3ff-white | Off-white | Off-white | Off-white | Running side/pulley side (Color) | |
| | | Friction cover (Material) | |
| | | Friction cover (Surface structure) | |
| | | Friction cover (Color) | |
| | | Traction layer (M aterial) | |
| | | Reverse cover (M aterial) | |
| | | Reverse cover (Surface structure) | |
| | | Reverse cover (Color) | |
| | | Product characteristics | |
| | | Drive determination | |
| | Yes | Yes | Yes | Yes | Slider bed suitable | |
| | Yes | Yes | Yes | Yes | Carrying roller suitable | |
| | Yes | Yes | Yes | Yes | Permanently antistatic | |
| | No | No | No | No | Food suitability, FDA conformance | |
| | | | | Technical key data | |
| | 4.0 | 2.1 | 2.1 | 5.2 | [mm] Thickness | |
| | 0.16 | 0.08 | 0.08 | 0.2 | [in.] | |
| | | | | | [mm] Nosebar Radius (minimum) | |
| | | | | | [in.] | |
| | 32 | 35 | 32 | 60 | [mm] Pulley diameter (minimum) | |
| | 1.3 | 1.4 | 1.3 | 2.4 | [in.] | |
| | 50 | 50 | 40 | 80 | [mm] Pulley diameter minimum with counterflection | |
| | 2.0 | 2.0 | 1.6 | 3.1 | [in.] | |
| | | | | [N/mm] Tensile force for 1% elongation (k1% after running-in) | |
| | | | | [lbs./in.] per unit of width (Habasit standard 320.013)Tensile force | |
| | 9 | | | 12 | [N/mm] for 1% elongation (k1% static) per unit | |
| | 51 | | | 69 | [lbs./in.] of width (Habasit standard 320.064) | |
| | | | | [N/mm] Tensile force for 1% elongation (k1% static) per unit | |
| | | | | [lbs./in.] of width (Habasit standard 320.111) | |
| | 75 | | | 11 | [N/mm] Tensile force for 1% elongation (k1% relaxed EN 1723) | |
| | 43 | | | 63 | [lbs./in.] per unit of width (Habasit standard 320.155) | |
| | | | | [N/mm] Tensile force for 2% elongation (k2% static) per unit | |
| | | | | [lbs./in.] of width (Habasit standard QAD-WI-10-35) | |
| | | | | | [N/mm] Tensile force for 8% elongation (k8% static) per unit | |
| | | | | | [lbs./in.] of width (Habasit standard 320.063) | |
| | | [N/mm] Nominal peripheral force per unit of width | |
| | | [lbs./in.] | |
| | -10/60 | -10/60 | -5/70 | -30/100 | [ C] Operating temperature, admissible (continuous) | |
| | 14/140 | 14/140 | 23/158 | -22/212 | [°F] | |
| | 0.15 | 0.15 | 0.15 | 0.15 | [ -] Coefficient of friction on driving pulley of steel | |
| | 2400 | 4000 | 4000 | 1200 | [mm] Seamless manufacturing width | |
| | 94 | 157 | 157 | 47 | [in.] | |
| | | | |
| | • | • | • | • | Thermofix | |
| | • | • | • | | Flexproof | |
| | | | | | Stepflex | |
| | | | | | Quickmelt | |
| | • | • | • | • | Mechanical | |
| | SAG-8E | SAQ-8E | SNB-8E | SAG-12E | | |
| | | | | | | |
