Ordering Information

MODEL SHAFT LINES IND OUT INTERP BASE CAB EXIT CONN DIA SPEC

5

MODELR119 - Cable length, inches 19 - mm body, ribbon cable 18 Standard R120 20-mm body, round cable EXITS SHAFTB Side-exit cable Blind hollow shaft S Solid shaft CONN - Connector P Pigtails (no connector) LINES - Disc line count00360 Y 8-pos ribbon cable socket connector(Berg 71602-308 or equal) ( , 00500, 00512, 00900, 01000, 01024 R119 only) Consult factory for other line counts S DE-9P ( R120 only) IND - Index format DIA - Shaft diameter Q Quarter-cycle gated index 02E 1/8” (
SHAFT = S or B ) 03M 3 mm (
SHAFT = S or B ) V - Input voltage 04M 4 mm (
SHAFT = S ) 5 +5 Vdc SPEC - Special features OUT – Output format # Issued at time of order to cover specialcustomer requirements L RS422 differential line driver N No special features INTERP - Interpolation factor 01, 02, 05, 10, 16BASEA A
CCESSORIES (order separately) Use with R119B or R120BB SCD-xxx-xxx Shaft coupling (see separate data sheet) Use with R119SC Use with R120S CAB M06 Mating connector for DE-9P

SPECIAL CAPABILITIESWARRANTY For special situations, we can optimize catalog industrial encoders to provide higher frequency response, greater accuracy, wider temperature range, reduced torque, non-standard line counts, or other modified characteristics. In addition, we regularly design and manufacture custom encoders for user-specific requirements. These range from high-volume, low-cost, limited- performance commercial applications to encoders for military, aerospace and similar high-performance, high-reliability conditions. We would welcome the opportunity to help you with your encoder needs.Gurley Precision Instruments offers a limited warranty against defects in material and workmanship for a period of one year from the date of shipment.

Gurley Precision Instruments514 Fulton StreetTroy, NY 12180 U.S.A.(800) 759-1844, (518) 272-6300, fax (518) 274-0336, Online at www.gurley.com, e-mail: info@gurley.com

R119S/R120B

Page 6 of 6

V3.1
