www.greenlee.com
GREENLEE.
Conduit Measuring Tape and Dispenser
• Fish and measure conduit runs in one operation.
• Permanently printed measurements every foot from zero to 3000
• Made of strong, waterproof polyester.
• Pay-out dispenser has anti-skid pads, handle and built-in cutter.
435 Measuring Tape shown on 434 Dispenser - sold separately.
«sa
"
CAT. NO. UPC NO.
DESCRIPTION
435 434
21562 21875
Conduit Measuring Tape 3/16" x 3000' (4.8 mm x 914 m) Pay-Out Dispenser for 435 Conduit Measuring Tape
SPECIFICATIONS
Size 3000' (914 m)
Capacity 130 lbs. (578 kN) average breaking strength
Weight 435: 18.4 lbs. (8.3 kg), 434: 3.5 lbs. (1.6 kg)
Double-Braided Composite Rope for High Force Cable Pullers
• Custom-made to Greenlee specifications to provide 4:1 Safety Factor required for cable pulling.
• Double-braided inner core with an extra double-braided outer jacket for added strength and less stretch; white with green tracer.
• Rot and mildew resistant.
• Factory spliced eyes at both ends.
• Lowest stretch.
• Select a rope with a maximum rated capacity that meets or exceeds the cable puller's maximum pulling force.
MAXIMUM RATED
AVERAGE
WEIGHT
ROPE
ROPE DIAMETER
ROPE LENGTH
CAT. NO.
UPC NO.
CAPACITY
BREAKING STRENGTH
LBS.
kg
STAND
FOR THE 805 PULLER
3/8"
300'
91 m
450
23773
1200 lbs.
3.6 kN
3700 lbs.
16.4 kN
14.3
6.5
406
600'
182 m
451
23775
1200 lbs.
3.6 kN
3700 lbs.
16.4 kN
31.0
14.3
644
(9.5 mm)
1,200'
365 m
452
23776
1200 lbs.
3.6 kN
3700 lbs.
16.4 kN
60.0
27.2
644
FOR THE UT2 PULLER
1/2"
(12.7 mm)
300'
91 m
2,200 lbs.
8.9 kN
10,000 lbs.
44.4 kN
34
600'
182 m
2,200 lbs.
8.9 kN
10,000 lbs.
44.4 kN
75
FOR THE 640 PULLER
300'
91 m
35283
35283
4,000 lbs.
17.8 kN
16,000 lbs.
71.1 kN
28
12.7
644
9/16"
(14.3 mm)
600'
182 m
35284
35284
4,000 lbs.
17.8 kN
16,000 lbs.
71.1 kN
63
28.6
644
1,200'
365 m
35285
35285
4,000 lbs.
17.8 kN
16,000 lbs.
71.1 kN
130
59
t
FOR THE 6001 & 6501 (UT5) PULLER
3/4"
300'
91 m
35098
35098
6,500 lbs.
28.9 kN
26,000 lbs.
115.6 kN
58
26.3
644
600'
182 m
35100
35100
6,500 lbs.
28.9 kN
26,000 lbs.
115.6 kN
113
51.3
654
(19.1 mm)
1,200'
365 m
35101
35101
6,500 lbs.
28.9 kN
26,000 lbs.
115.6 kN
230
104.3
t
FOR THE 6800 (UT8) PULLER
7/8"
300'
91 m
34136
34136
8,000 lbs.
35.6 kN
32,000 lbs.
142.3 kN
90
40.8
654
600'
182 m
34137
34137
8,000 lbs.
35.6 kN
32,000 lbs.
142.3 kN
178
80.7
654
(22.2 mm)
1,200'
365 m
34138
34138
8,000 lbs.
35.6 kN
32,000 lbs.
142.3 kN
359
163.3
t
\3 Co
. .
fy> ca
Oo vi
3 6
Co CT)
t l
vi ca
t This rope does not fit on a rope stand. Use reel jacks and a spindle to dispense. See pages 365-366
REPLACEMENT PART fj=ACCESSORY
