AIR TREATMENT FOR AIR MOTORS FRL units Phone: +31 – 172 –426608 Fax: +31 – 172 426607 Website: www.globe-benelux.nl e-mail: info@globe-benelux.nl FRL UNITS FOR GLOBE AIR MOTORS • Pre selected for use on GLOBE air motors; • Standard with ATEX II cat. 2 G&D T5 for use in hazardous environments; • All filters have a float type auto-drain; • The FRL units are ready to mount and supplied with a pressure gauge. Specifications Model / ordering code GFRL3/8 GFRL1/2 GFRL3/4 GFRL1 GFRL11/2 GFRL2 Port size 3/8” ½” ¾” 1” 1½” 2” Max. operating pressure 10 bar Set pressure range 0,5 – 8,5 bar Ambient and fluid temperature -5 to 60 ºC Nominal filtration rating 5 ìm Max. flow rate (L/ sec. free air) 25 50 75 165 200 265 Pressure drop (Äp) at 7 bar (105 psi) and max. flow rate 1 bar 1,2 bar 1,4 bar 1,5 bar 1,3 1,1 Housing material Aluminium Bowl material Polycarbonate Weight (kg) 0,75 1,41 4,17 4,34 7,5 12 Recommended lubricant Class 1 turbine oil (ISO VG32) FRL unit / air motor selection Vane air motors Piston air motors V1 V2 V4 V6 V8 V10 RM110 RM210 RM310 RM410 RM510 RM610 GFRL3/8 X X GFRL1/2 X X GFRL3/4 X X GFRL1 X X X2 X GFRL11/2 X2 X2 X GFRL2 X2 X X X2 = for maximum power at high speed of rotation. Consult GLOBE Airmotors BV or their distributors for other motor types and models.
