2008 Standard Products Catalog
248Pages

{{requestButtons}}

Catalog excerpts

2008 Standard Products Catalog - 2

EASAct ComplaintGEMotors X$D UltraX$D Ultra 841 X$D Ultra 661 Energy $aver > EISAct 2007 President George W. Bush signed the Energy Independence and Security Act (EISAct) December 19, 2007. It requires general purpose motors to meet efficiency levels based on NEMA MG1 table 12-12 within three years from the date of signing (12/19/10). Look for the EISAct 2007 Compliance sticker to ensure your motor is compliant. Inverter Capabilities GE Motors has different insulation systems for motor, which operate on Inverter power. Each system can withstand a peak Corona Inception Voltage with a rise...

Open the catalog to page 2
2008 Standard Products Catalog - 3

841 3.17Standard Features 3.18Pricing 3.22C-Face Pricing 3.23460V Performance Data 3.25575V Performance Data 3.27Dimensions > Ι 1.1Open Dripproof 3.33X$D Ultra 1.17Explosion Proof 1.7TEFC and TEFC-Severe Duty > 661 for Heat Exchanger 1.20Kits and Accessories 1.1Standard Features 1.2Pricing 1.6NEMA Dimensions 1.17Standard Features 1.18Pricing 1.19NEMA Dimensions 1.7Standard Features 1.8Pricing1.12C-Face Pricing 1.14NEMA Dimensions 1.15C-Face Dimensions 3.29Standard Features 3.30Pricing 3.31460V Performance Data 3.32Dimensions > ή , X$D Ultra > 841 and 661 Kits 140 to 449T3.36X$D Ultra > ή...

Open the catalog to page 3
2008 Standard Products Catalog - 6

Data subject to change without notice. GEP-500T 03/08. >

Open the catalog to page 6
2008 Standard Products Catalog - 7

Feature Value Line ODP Value Line Epact TEFC Frame Size 140-449 140-280 320-360 400-445 447-449 Agency Approvals UL, CSA UL, CSA UL,CSA UL, CSA UL, CSA Altitude 3300 ft @ 40C 3300 @ 40ںC 3300 ft 3300 ft 3303 @ 40C Ambient 40 to -15ںC 40 to -40C -10 to 40ںC -10 to 40C -10 to 40ںC Bearing Cap Gasketed Yes, 440 No No No No Bearing Caps 280TS DE and ODE 280TS Only Yes Yes Yes Bearing Life (hrs.) Direct Coupled: 65,000Belted: 25,000 Direct Coupled: 65,000Belted: 25,000 Direct Coupled: 65,000Belted: 26,280 Direct Coupled: 65,000Belted: 26,280 Direct Coupled: 65,000Belted: 26,280 Bearing Type...

Open the catalog to page 7
2008 Standard Products Catalog - 8

Feature Value Line Epact XP A$D Frame Size 140-365 140-180 210-250 280-320 Agency Approvals UL, CSA UL UL UL Altitude 3300 @ 40C 3300 @ 40ںC 3300 @ 40C 3300 @ 40ںC Ambient 40 to -15C 40 to -40ںC 40 to -40C 40 to -40ںC Bearing Cap Gasketed No Bearing Caps No DE DE DE Bearing Life (hrs.) Direct Coupled: 40,000Belted: 20,000 Direct Coupled: 130,000Belted: 26,280 Direct Coupled: 130,000Belted: 26,280 Direct Coupled: 130,000Belted: 26,280 Bearing Type 140-280T - Shielded 280TS, 320-365 - Open Shielded Shielded Shielded Conduit Box Cast Iron Cast Iron Cast Iron Cast Iron Constant Torque...

Open the catalog to page 8
2008 Standard Products Catalog - 9

Feature Energy $aver ODP Energy $averή TEFC Frame Size 140-280 320-440 140-320 360-449 Agency Approvals UL, CSA UL, CSA UL - Component and Insulation SystemRecognition, CSA - Motors and C-390 UL - Component and Insulation SystemRecognition, CSA - Motors and C-390 Altitude 3300 ft @ 40C 3300 ft @ 40ںC 3300 ft 3300 ft Ambient 40 to -20C 40 to -20ںC 40 (degree symbol) C 40 (degree symbol) C Bearing Cap Gasketed No No No No Bearing Caps No >320 inner cap440T external cap only None None Bearing Life (hrs.) Direct Coupled: 65,000Belted: 26,280 Direct Coupled: 65,000Belted: 26,280 Direct Coupled:...

Open the catalog to page 9
2008 Standard Products Catalog - 10

Feature Ultra Ultra 841 Ultra 661 Frame Size 140-449 140-449 143-365 Agency Approvals UL,CSA, CE UL,CSA, CE UL, CSA, CE Altitude 3300 ft @ 40C 3300 ft @ 40ںC 3300 ft @ 40C Ambient 40 to -40ںC 40 to -25C 40 to -25ںC Bearing Cap Gasketed Yes Yes Yes Bearing Caps Yes Yes Yes Bearing Life (hrs.) Direct Coupled: 130,000Belted: 26,280 Direct Coupled: 130,000Belted: 26,280 Belted: 40,000 Bearing Type Single Shielded Single Shielded Roller Bearings Conduit Box Cast Iron Cast Iron Cast Iron Constant Torque 20:1 (Exceptions Pg. iii) 20:1 (Exceptions Pg. iii) Efficiency NEMA Premium NEMA Premium NEMA...

Open the catalog to page 10
2008 Standard Products Catalog - 11

* Min Speed is 600RPM**Note Constant Torque Speed Range***2400 volt system for 320 frame and large. All other frames GEGARD2000, 2000 Volt system 1.0 SF40 degree C amb 3300 ft altitude Contact GE Motors technical support for more information or specific application data. Inverter Duty Capabilities Data subject to change without notice. GEP-500T 03/08.

Open the catalog to page 11
2008 Standard Products Catalog - 12

Data subject to change without notice. GEP-500T 03/08. >

Open the catalog to page 12
2008 Standard Products Catalog - 13

ODP ٙ HP Range 1-400 > Value Line Poles 2,4,6 Voltage 200, 230/460, 460, 575 Efficiency EPAct through 200 HP Frequency 60 NEMA Design A or B Agency Approvals UL - Component and Insulation System Recognition, CSA - Motors and C-390 Altitude 3300 ft Ambient 40C Balance/Vibration 143-405: .001 in max, 444-449: .0012 in max Bearing Caps 284TS-286TS and 324-449 Bearing Protection Shaft Slinger on 444-449 Bearing Type Ball, 143T-286T Sealed 284TS-286TS and 324-449 Open Conduit Box Stamped Steel, rotatable End Shield Cast Iron Fasteners Metric, ISO 8.8 Frame Material Cast Iron Frame Size 143-449...

Open the catalog to page 13
2008 Standard Products Catalog - 14

Data subject to change without notice. GEP-500T 03/08. size="-1">

Open the catalog to page 14
2008 Standard Products Catalog - 16

Data subject to change without notice. GEP-500T 03/08. size="-1">

Open the catalog to page 16
2008 Standard Products Catalog - 18

Data subject to change without notice. GEP-500T 03/08. size="-1">

Open the catalog to page 18
2008 Standard Products Catalog - 19

TEFC and TEFC-SD ٙ Value Line HP Range .75-250 Poles 2, 4, 6 Voltage 200, 230/460, 460, 575 Efficiency EPAct Frequency 60 Hz NEMA Design A or B Agency Approvals UL - Component and Insulation System Recognition, CSA - Motors and C-390 Altitude 3300 ft Ambient 40C Balance/Vibration 143-449: NEMA MG1 Standard Bearing Cap 284TS-286TS and 324-449 Bearing Protection Shaft Slinger Bearing Type Ball, 143T-286T Sealed; 284TS-286TS and 324-449 Open Conduit Box 143-286: Stamped Steel, 324-449: Cast Iron Drains 2 holes End Shield Cast Iron Fasteners 143-286 Metric, 324-449: SAE Frame Material Cast Iron...

Open the catalog to page 19
2008 Standard Products Catalog - 20

Value Line Data subject to change without notice. GEP-500T 03/08. size="-1">

Open the catalog to page 20
2008 Standard Products Catalog - 22

Value Line Data subject to change without notice. GEP-500T 03/08. size="-1">

Open the catalog to page 22
2008 Standard Products Catalog - 24

Data subject to change without notice. GEP-500T 03/08. size="-1">

Open the catalog to page 24
2008 Standard Products Catalog - 28

Data subject to change without notice. GEP-500T 03/08. >

Open the catalog to page 28
2008 Standard Products Catalog - 29

TEFC-XP ٙ HP Range 1.5-75 Poles 2,4,6 > Value Line Voltage 230/460 Efficiency EPAct Frequency 60 NEMA Design A or B Agency Approvals UL - Motor Listing and Insulation System Recognition, CSA - Motors Altitude 3300 ft Ambient 40C Balance/Vibration 0.11 in/sec Max. Bearing Protection Brass Shaft Slinger - DE and ODE Bearing Type Ball, 143T-286T Sealed; 284TS-286TS and 324-365 Open Conduit Box Cast Iron Drains Yes End Shield Cast Iron Fan Non Sparking Fan Cover Steel plate Fasteners Metric Frame Material Cast Iron Frame Size 182-365 Grease Grease: 182T-286T: Lithium 284TS-286TS and 324-365:...

Open the catalog to page 29
