ROTOPACK

Leakproof, axial and radial, single and multiple rotating unions with elastic contact seals. Extremely wide range of designs, sizes and materials allowing high pressure and thermal loads. Designed for a large number of media. Suitable for swivelling movements up to mid-range speeds (depending on pressure, diameter, and model). Optimal performance for a variety of applications due to standard products.

ROTOPACK single rotating union

Rotating unions with either straight or right- angled single channels which can be fitted in axially to the customer’s component. One model also allows radial fitting to the customer’s shaft. ROTOPACK single rotating unions (standard) ROTOPACK multiple rotating unions (standard) Pressure: 5,800 psiNominal sizes: up to 150 mm Materials:steel, nickel-plated steel, stainless steel, alminum Media:oil, water, air, gases, all liquids, vacuum Type of mounting: threaded up to 3” or flanged Speeds:1,500 rpm, dependent on pressure, size (see p/v diagram on data sheets)
ROTOPACK multiple rotary shaft connection (standard) ROTOPACK single rotating union (standard)

ROTOPACK multiple rotating unions

Rotating unions with multiple channels which be fitted axially to the customer’s component. Pressure: up to 5,800 psiNominal sizes: 6 - 31 mm No. of channels:2 - 10Materials:steel, nickel-plated steel, stainless steel, aluminumMedia:oil, water, air, gases, all liquids, vacuum Type of mounting: flanged Speeds:up to 500, dependent on pressure and size (see p/v diagram on data sheets) 8
