Motor Mounted Rotary Vane

1.1 or 1.3 cfm

Lubricated orOilless 0211 Series

MODEL 0211 SERIES

LUBRICATED: 20" HG MAX., VAC., 20 PSI MAX. PRESSURE1.3 CFM OPEN FLOW

Lubricated (Lab Model)

OILLESS: 20" HG MAX., VAC., 15 PSI MAX. PRESSURE 1.1 CFM OPEN FLOW

0211 LAB MODEL

(Lubricated)

Oilless Version

Specially accessorized for laboratory use. 20" HG MAX. VAC., 20 PSI MAX. PRESSURE 1.3 CFM OPEN FLOW

Product Dimensions

( mm ,inches) Dimensions are for reference only. PRODUCT FEATURES

?Lubricated or oilless operation?Motor mounted ?Rugged construction/low maintenance?Essentially pulse-free service?Built-in pressure relief valve on standard units(Non-Lab Models)

5.62142,7 12.8APPROX.325,1 OUTLET1/4 NPT 2.75 69,9 INLET1/4 NPT6.19APPROX.157,2 3.52APPROX.89,4 6.56APPROX.166,6

INCLUDES

Lubricated Standard Models: ?Muffler V425B ?Filter/oiler AA680K Oilless Standard Models:

4.25108,0 0.5012,7 3.8497,5 2.75 69,9

?Muffler/filter AA617G (2) Lab Models (Lubricated): ?Gauges – Vacuum AA640, Pressure AA644B ?Hose barbs AA254C ?Regulators AA986B ?Carrying handle AC174 ?Cord with on/off switch AA896 ?Foot support assembly AC136 ?Oiler/filter AA680J ?Muffler AB580B 5.62142,7 11.99APPROX.304,5 1/4 NPT (2) 3.00APPROX.76,2 6.15APPROX.156,2 6.53APPROX.165,9

RECOMMENDED ACCESSORIES

?Vacuum relief valve AA840A ?Vacuum gauge AA640 (Standard Models) ?Pressure gauge AA644B (Standard Models) ?Oil AD220 ?Repair kit K216 (Lubricated Vacuum Models) ?Repair kit K217 (Lubricated Pressure plus Lab Models) ?Repair kit K218 (Oilless, Pressure or Vacuum) 4.50114,3 0.5012,7 5.63143,0 6.62REF.168,1 2.7569,9

Lab Model (Lubricated) Lubricated Version Oilless Version

9
