Separate Drive Rotary Vane

25, 35 and 45 cfm

Oilless 80 Series

MODEL 2080 SERIES

26" HG MAX. VAC., 25 CFM OPEN FLOW 15 PSI MAX. PRESSURE

MODEL 2080 DUAL FUNCTION

Model shown without gauge or relief valve which are attached on standard motor mounted units.

Ideal for graphic arts applications where simultaneousvacuum and pressure are needed. 9 PSI MAX. PRESSURE (@ 18" HG)

Product Dimensions

( mm ,inches) 15 CFM OPEN FLOW (PRESSURE SIDE) Dimensions are for reference only.

6.53165,9 0.875 22,2 MODEL 2080

MODEL 3080 SERIES Vacuum Pump

1.125

26" HG MAX. VAC., 35 CFM OPEN FLOW

Top View Side View

BORE 28,6 MODELS 3080, 4080

15 PSI MAX. PRESSURE

15.67398,0 11.69296,9

MODEL 3080 DUAL FUNCTION

3.6993,7

Ideal for graphic arts applications where simultaneousvacuum and pressure are needed.

5.85148,6

9 PSI MAX. PRESSURE (@ 18" HG)

3/4" NPT MODELS 2080,3080 1" NPT MODEL 4080

21 CFM OPEN FLOW (PRESSURE SIDE)

2.28 BORE 57,9 APPROX. 29.11 739,4 MODEL 4080 27.96 710,2 MODELS 2080, 3080

MODEL 4080 SERIES

13.27337,1

25" HG MAX. VAC., 45 CFM OPEN FLOW

11.85301,0

15 PSI MAX. PRESSURE

4.50114,3 11.75 298,5 APPROX.

MODEL 4080 DUAL FUNCTION

Ideal for graphic arts applications where simultaneousvacuum and pressure are needed.

Compressor

2.28 6.53 165,9 3/4" NPT MODELS 2080,3080

9 PSI MAX. PRESSURE (@ 18" HG)

0.875 57,9 APPROX. 1" NPT MODEL 4080 BORE 22,2 MODEL 2080

25 CFM OPEN FLOW (PRESSURE SIDE)

Top View Side View BORE 1.125 28,6 MODELS 3080, 4080 3.6993,7 11.69296,9

PRODUCT FEATURES

? Oilless operation? Rugged construction/low maintenance? Low noise 5.85148,6 15.67 398,0 APPROX. 29.11 739,4 MODEL 4080 27.96 710,2 MODELS 2080, 3080

INCLUDES

13.27337,1 ? Internal sound suppression ? Heavy duty internal filtration ? Vacuum adjustable relief valve *AN226,metric version AN226A (Vacuum Pump, Dual Function)? Pressure adjustable relief valve *AN225,metric version AN225A (Compressor, Dual Function)? Vacuum gauge *AA640 (Vacuum Pump, Dual Function) ? Pressure gauge *AA644B (Compressor, Dual Function)* Not included in separate drive models 11.85301,0 4.50114,3

Dual Function Models

3/4" NPT (PRESSURE SIDE) MODELS 2080,3080

Top View Side View

1" NPT (PRESSURE SIDE) MODEL 4080 6.53 165,9 BORE 0.875 22,2 MODEL 2080 BORE 1.125 16.06407,9 28,6 MODELS 3080, 4080 3.6993,7

RECOMMENDED ACCESSORIES

11.69296,9 3.6993,7

? Filter/muffler kits:K552 (Compressor or Vacuum Pump) K547 (Dual Function Models)? Complete repair kits:K546 (Compressor or Vacuum Pump) K551 (Dual Function Models)

5.85148,6 3/4" NPT (VAC. SIDE) MODELS 2080,3080 1" NPT (VAC. SIDE) MODEL 4080 2.28 29.11 MODEL 30.04 MODEL 57,9 APPROX. 27.96 MODEL 710,2 2080 739,4 3080 763,0 4080 14.55 369,6 APPROX. 13.27337,1 4.50114,3 11.85301,0
