Worldwide Excellence in Air Technology –

Dedicated to the Success of Your Pneumatic Applications

AIR COMPRESSORS • VACUUM PUMPS

ROTARY VANE COMPRESSORS & VACUUM PUMPS - 7063 Rotary Vane

Gast Rotary Vane air compressors and vacuum pumps are used inthousands of applications worldwide. Available in oilless, lubricated, motor-mounted and separate drive styles, they offer a wide choice ofcapabilities including air flow from .31 to 112 cfm (0,53 to 190 m
3 /h); vacuumup to 29.5 in. Hg (13 mbar); and pressure up to 30 psig (2,1 bar); also available are dual function styles. Electric motors are dual frequency, multi-voltage ACfor worldwide applications, with smallest models rated 12 and 24 volts DC.Horsepowers range from
1 /
45 to 15 HP (0,02 to 11,1 kW). Vacuum tank systemscome in simplex and duplex variations, with tank sizes ranging from 2 to60 gallons. A complete line of recommended accessories is also available. Here’s how our Rotary Vane performance compares with that of our other popular positive displacement vacuumpumps and compressors. Use these charts to see if a Rotary Vane pump is the right choice for your application.
Diaphragm Linear Free Air FlowMaximum PressureMaximum Vacuum PistonRocking Piston Rotary Vane 112 CFM CFM 0510152025 PSI 050100150200 HG 051015202530 m 3 /h 010203040 bar 024681012 mbar 10008006004002000

Why use a Rotary Vane pump?

smooth,pulse-free air flow

Typical Applications

Rotary Vane vacuum pumps and compressors have certain significant advantages. In addition to providing economical to install and operate, without receiver tanks, they are compact(or equivalently offer high flow capacities for a given size), are simple and have lowstarting and running torque â–ª Breathing Air Supply â–ª Office/BusinessMachines requirements, produce minimalnoise or vibrations, â–ª Circulation Therapy are capable of long, service-free life andare â–ª Packaging â–ª Food ProcessingEquipment easily serviced. â–ª Graphic Arts â–ª Laboratory Use If these features are what you need in your pneumaticapplication, a Gast Rotary Vane model can provide you the right solution. â–ª Pond Aeration â–ª Vacuum Hold-Down â–ª Soil Sparging â–ª Air Sampling â–ª Vacuum Forming â–ª Air Bearings
The units that we list in this catalog are a small portion of whatwe actually make. Those listed are considered “standard units” and are normally available from stock in small quantities. Variations are produced for many customers and by passing on to us the application specifications we might find an existing unit that fits your requirement. If we don’t and the quantity is sufficient, we will design a “special unit” for the application.Pictorial and dimensional data is subject to change without notice. The information presented in this catalog is based on technicaldata and test results of nominal units. It is believed to be accurate and is offered as an aid in the selection of Gast products. It is the user’s responsibility to determine suitability of the product for intended use and the user assumes all risk and liability what- soever in connection therewith. Warning: Units Should Not Pump CombustibleGases or Be Used in Combustible Ambients
2
