Oilless Miniature Rocking Piston

to .83 cfm

LOA Series

SHADED POLE MOTOR

90 PSI MAX. PRESSURE, 25" HG MAX. VACUUM .38 CFM OPEN FLOW

PSC MOTOR

100 PSI MAX. PRESSURE, 26" HG MAX. VACUUM .83 CFM OPEN FLOW

DC MOTOR

100 PSI MAX. PRESSURE, 27" HG MAX. VACUUM .62 CFM OPEN FLOW

PRODUCT FEATURES

• Oilless Operation• Motor Mounted • Rugged construction / low maintenance• Low noise levels

INCLUDES

• Capacitor AG331 (HB, HD motors) AF485A (NL motor) AH364 (NQ motor) AC Models (capacitor shipped unattached) DC Models

Product Dimensions (Inches, mm ). RECOMMENDED ACCESSORIES

• Muffler/filters AH190• Pressure gauge AF583 / Vacuum gauge AA640• Pressure relief valve AF592S / Vacuum relief valve AA207 • (3) Rubber feet AF584A • Repair Kit K476

.8120,571.6241,157.98 APPROX202,70 .358,902.1454,4 1/4 NPT Outlet1/4 NPT Inlet #10-32 THRU (2)2.1253,854.60116,84#10-32 UNF-2B x.50 DEEP1.7544,451.7544,455.71 APPROX145,03 5.97151,645.57141,48 .8120,571.6241,15 1.7544,451.7544,452.1253,85 1/4 NPT Outlet1/4 NPT Inlet .358,89 5.10129,544.28108,71 5.97151,645.56141,22#10-32 UNF-2B#10-32 THRU

9.15232,41
