Product and Application Information

AIR COMPRESSORS • VACUUM PUMPS

Rocking Piston - 7063 Rocking Piston

Gast oilless Rocking Piston air compressors and vacuum pumps, available in standard, twin, and miniature styles, make them the perfect choice for hundreds of applications. Air flow capabilities from 3.4 lpm to 5.5 cfm (9,35 m
3 /h) are available as are vacuum capabilities up to 29 in. Hg (31 mbar) and pressure to 175 psig (12 bar). Choose from dual frequency, shaded pole, and permanent split capacitor (psc) electric motors with AC multi-volt- ages available for worldwide applications as well as 6, 12, and 24 volt DC models in brush and brushless types. Horsepowers range from
1 /
1 20 to /
2 HP (0,04 to 0,37 kW). Tank models and a complete line of recommended acces-sories are also available. Here’s how our Rocking Piston performance compares with that of our other popular positive displacement vacuum pumps and compressors. Use these charts to see if a Rocking Piston pump is the right choice for your application.
Free Air FlowMaximum PressureMaximum Vacuum Piston Rocking Piston Rotary VaneDiaphragmLinear 112 CFM CFM 0510152025 PSI 050100150200 HG 051015202530 m 3 /h 010203040 bar 024681012 mbar 1000800600400200

Why use a Rocking Piston pump? Typical Applications

The rocking piston combines the best characteristics of piston and diaphragm air compressors into a small unit with exceptional performance. Pressure to 175 psi, 12, 0 bar. Units as light as 7 pounds 3.2 kg. Tank-mounted units, DC powered models. AC motors to match North American, European and worldwide power supplies. Because Gast ROC-R pumps are oil-free, they are ideal for use in applications in laboratories. Hospitals and the food industry where oil mist combination in undesirable. These pumps are made to stand up through years of use. The piston rod and bearing assembly are bonded together, not clamped; they will not slip, loosen or misalign to cause trouble. 6 Oxygen Concentrators 6 Beverage Dispensing 6 Body Fluid Analysis 6 Automotive Suspension 6 Dental Vacuum Ovens 6 Vacuum Frames 6 Core Drilling
The units that we list in this catalog are a small portion of what we actually make. Those listed are considered “standard units” and are normally available from stock in small quantities. Variations are produced for many customers and by passing on to us the appli-cation specifications we might find an existing unit that fits your requirement. If we don’t and the quantity is sufficient, we will design a “special unit” for the application.Pictorial and dimensional data is subject to change without notice. The information presented in this catalog is based on technical data and test results of nominal units. It is believed to be accurate and is offered as an aid in the selection of Gast products. It is the user’s responsibility to determine suitability of the product for intended use and the user assumes all risk and liability what- soever in connection therewith. 2
