REGENAIR

®

Regenerative Blowers Worldwide Excellencein Air Technology-

Smart Air Solutions for Your World

Regenerative Blowers

The Gast full line of Regenair
® Regenerative Blowers forhigh volume vacuum or compressed air applications offersboth motor-mounted and separate drive models. Air flowcapabilities range from 27 to 1350 cfm (46 to 2294 m
3 /h),vacuum capabilities up to 183 in. H
2 O (13.5 in. Hg/456mbar), and pressure capabilities up to 284 in.H
2 O (10.25psig/707 mbar). TEFC electric motors are UL and CSAcertified on several models and come in single and three-phase, dual frequency, and multi-voltage versions forworldwide applications; 12 volt DC is available on thesmallest model. Horsepowers range from 1/8 to 30 HP(0,09 to 22,4 kW).The explosion-proof motors series, designed primarily forsoil vapor extraction operations, have air flow capacities upto 425 cfm (722 m
3 /h), with vacuum levels to 110 in. H
® 2 O(8.1 in. Hg/274 mbar) and pressure capabilities up to 100 in.H

Regenair Blower Featuresand Benefits

2 O (3.6 psig/249 m/bar). Motors range from 1/3 to10 HP(0,25 to 7,5 kW). A complete line of recommended accesso-ries for all blower series is also available.?Complete line of blowers satisfies all single and three-phase motor requirements?Low noise operation?Continuous, non-pulsating, oil-free air flow?Low maintenance ?Fan cooling dissipates heat around the bearings to helpprolong bearing life?Performance modifications and/or special requirementscan be accommodated Standard Motor Mounted Models ?Rugged construction of cast aluminum or cast iron,depending on model size?UL and CSA approved motors; TEFC on single-endedmodels, OPEN on dual-ended models?Permanently sealed ball bearings incorporate new polyureagrease that extends bearing life and offers superior resistance to washout, rust and corrosion?Integrated mufflers on single-ended models minimizeoperating noise Explosion-Proof Motor Series ?UL and CSA approved explosion-proof multi-voltage motorswith thermal protection?Double sealed ball bearings with a B10 life exceeding30,000 hours of continuous operation at the maximum ratedcontinuous blower load?Sealed air streams; leak tested to less than 5 cc/min The Regenerative Principle In a regenerative blower, the com-pression space consists of a hollow, circular ring between the tips of theimpeller blades and the walls of thehousing. In operation, the rotating impeller draws in air from the inletport into the compression space and moves it radiallyoutward to the curved housing by centrifugal force.The action is called “regenerative” because a certainamount of air slips past each impeller blade during rotationand returns to the base of a succeeding blade forreacceleration.Because of this dynamic principle, regenerative blowers cangenerate pressure and vacuum performance comparable tomany multi-stage or positive displacement blowers. Separate Drive Series ?Drive pulley size can be changed to lower speeds and adjustperformance?Built-in acoustical muffling reduces operation noise?Precision balanced impellers provide low vibration operation
