Miniature Plastic Pumps

Worldwide Excellence in Air Technology –

Dedicated to the Success of Your Pneumatic Applications

AIR COMPRESSORS • VACUUM PUMPS

Designed with the OEM in mind for those compact applications, Gast’sminiature plastic compressors and vacuum pumps offer versatility with solid performance and dependability. Backed by a reputationfor product quality, customer satisfaction, and providing pneumaticsolutions, Gast Manufacturing Incorporated has been setting the industry’s standard of excellence throughout the world for over 85years. And with our ISO 9001 and ISO 14001 certifications, we assureour customers that our products and processes meet the most stringent quality and environmental standards.Count on us to respond quickly to your custom requirements with qualityproducts delivered on time.

Miniature Diaphragm Table of Contents / Performance Overview

MODEL /SERIESPOWER RATING @ 60 Hz hp kW MAXIMUM PRESSURE psi barMAXIMUMVACUUM “Hg mbarPAGENO. FREE AIR FLOW50 Hz 60 Hz

Features and Benefitsof our Miniature Pumps

2D (DC)--.65 lpm5.50,38116413 3D (DC)--1.18 lpm7.10,4911.36314 5D (DC)--1.5 lpm110,761357355D (DC) Twin--1.6-2.6 lpm50,34222685

AC and DC Models

10D (AC)---3.8 lpm151,0155057

Low noise, low vibration

10D (DC)--4.3 lpm151,0145267 15D (AC)--5.2 lpm7.0 lpm241,6203358

Compact, lightweight

15D (DC)--7.0 lpm201,4203358 15D (DC) Twin--6-13 lpm251,7259910

Oilless

22D (DC)1/80,091.3 cfm / 2,2 m 3 /h251,722.525111 22D (AC)1/200,04-.7 cfm / 1,2 m 3 /h251,72323412

Long life

20R (AC)1/300,2514-16 lpm30-452,1-3,120-25335-9913 *34R(DC)1/4,175 1 cfm15010,35-----15 8R (DC)--3.4 lpm22.51,61743816Available in summer 2006

Corrosion resistant Low power consumption

Typical Applications

â–ª Air and gas analysis â–ª Ambulance/emergency vehicles â–ª Pest control equipment â–ª Blood pressure monitors â–ª Vacuum pick-and-place for electronic industry â–ª Oil atomizers â–ª Respiration monitors â–ª Tape drives â–ª Portable aspirators â–ª Portable dosimeters â–ª Ink-jet printers â–ª Breast pumps â–ª Air brushes â–ª Package labeling equipment â–ª Body fluid analysis â–ª Agricultural foam markers â–ª Lab equipment â–ª Sterilizers â–ª Crop sprayers
Warning: Units Should Not PumpCombustible Gases or Be Used inCombustible Atmospheres Pictorial and dimensional data is subject to change without notice.Various brand name motors are used on any model at the discretion of Gast Manufacturing Inc.Note that several models in this catalog have brushless DC motors which are referred to as BLDC.The information presented in this catalog is based on technical data and test results of nominal units. It is believed tobe accurate and is offered as an aid in the selection of Gast products. It is the user’s responsibility to determine suit- ability of the product for intended use and the user assumes all risk and liability whatsoever in connection therewith. 2 Gast Manufacturing Inc., A Unit of IDEX Corporation, Benton Harbor, MI USA • ph 269-926-6171 • fax 269-925-8288 • www.gastmfg.com ®Registered Trademark/™Trademark of Gast Manufacturing Inc., Copyright ©2005 Gast Manufacturing Inc. All rights reserved.
